Запчасти Doosan Daewoo STEERING UNIT STEERING PIPING

-

420-00027A

STEERING UNIT

desc: DIRECTION

1шт.

1

2.115-00194

RING;DUST SEAL

SC: K

1шт.

2

-

HOUSING;SPOOL AND SLEEVE

SC: D

1шт.

3

2.148-00001

BALL #8.5MM

desc: BILLE

1шт.

4

2.408-00128

THREAD BUSHING WITH PIN

desc: BROUCHE

1шт.

5

2.180-00199

O-RING

SC: K

1шт.

7

2.109-00085

BEARING ASS'Y

desc: PALIER

1шт.

8

2.115-00080

RING

desc: BAGUE

1шт.

9

2.123-00129

PIN;CROSS

desc: BROCHE

1шт.

11

2.405-00086

SHAFT;CARDAN

desc: TOURNEVIS EN CROIX

1шт.

12

2.131-00501

SET;SPRING

desc: ENSEMBLE DE RESSORT

1шт.

13

K9001364

O-RING

SC: K

3шт.

14

2.412-00143

PLATE;DISTRIBUTOR

desc: PLAQUE

1шт.

15

2.403-00296

SET;GEAR WHEEL

desc: ENSEMBLE DE PIGNON

1шт.

17

2.430-00295

COVER;END

desc: COUVERCLE

1шт.

18

K9001365

WASHER

SC: K

7шт.

20

2.120-00509

SCREW;SPECIAL

desc: VIS

1шт.

21

2.120-00467

SCREW

desc: VIS

6шт.

32

2.421-00080

VALVE;CHECK

desc: VANNE

1шт.

33

K9003553

SCREW

desc: VIS

1шт.

34

-

BALL

SC: D

1шт.

*

2.911-00060

SEAL KIT

desc: KIT DE REPARATION

1шт.
