Запчасти Doosan Daewoo LOAD ISOLATION SYSTEM OPTION PARTS

-

K1007254C

LOAD ISOLATION SYSTEM

SC: D

-2шт.

1

K1003140

VALVE;SHOCKLESS

SERIAL: 5001-5062

1шт.

1

K1018299

VALVE;SHOCKLESS

SERIAL: 5063

1шт.

2

K1006256

BRACKET;ACCUMLATOR

SERIAL: 5001-5095

1шт.

2

K1006256A

BRACKET;ACCUMLATOR

SERIAL: 5096

1шт.

3

K1006260

BRACKET;ACCUMLATOR

desc: SUPPORT

1шт.

4

K1003148

ACCUMULATOR

desc: RESERVOIR

1шт.

5

K1004674A

PIPE;RETURN

desc: CONDUITE DE RETOUR

1шт.

6

K1004679A

PIPE;BOOM UP('A2')

desc: CONDUITE

1шт.

7

K1004684A

PIPE;BOOM DOWN('B2')

desc: CONDUITE

1шт.

8

K1010676

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

9

DS2232111

ADAPTER

desc: RACCORD ADAPTATEUR

3шт.

10

DS2232051

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

11

K1010547

PLUG

desc: BOUCHON

1шт.

12

4215-1003D4

FLANGE;SPLIT

desc: BRIDE

2шт.

13

2181-9086

FLANGE;SPLIT

desc: FLASQUE EN DEUX PARTIES

4шт.

14

2180-1026D23

O-RING

desc: JOINT TORIQUE

3шт.

15

2180-1026D37

O-RING

desc: JOINT TORIQUE

3шт.

16

S8000291

O-RING

desc: JOINT TORIQUE

4шт.

17

S8030161

O-RING

desc: JOINT TORIQUE

2шт.

18

DS2026149

HOSE

desc: TUYAU FLEXIBLE

1шт.

19

DS2025056

HOSE

desc: TUYAU FLEXIBLE

1шт.

20

DS2025055

HOSE

desc: TUYAU FLEXIBLE

1шт.

21

DS2023252

HOSE

desc: TUYAU FLEXIBLE

1шт.

22

S2214066

BOLT

desc: BOULON A 6 PANS

3шт.

23

S2218566

BOLT

desc: BOULON A 6 PANS CREUX

8шт.

24

S2212266

BOLT

desc: BOULON DE PLOT

4шт.

25

S5110603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

26

S2216266

BOLT

desc: BOULON A 6 PANS CREUX

8шт.

27

DS0402011

WASHER;SPRING

desc: RONDELLE ELASTIQUE

3шт.

28

DS0001078

BOLT

desc: BOULON A 6 PANS

3шт.

29

DS0025017

BOLT

desc: BOULON A 6 PANS

6шт.

30

DS0025032

BOLT

desc: BOULON A 6 PANS

4шт.

31

S4012533

NUT

desc: ECROU

4шт.

32

S0561766

BOLT

desc: BOULON

2шт.

33

S4012733

NUT

desc: ECROU

4шт.
