Запчасти Doosan Daewoo MAIN PUMP-ROTARY GROUP HYDRAULIC PARTS

1

K9002177

ROTARY GROUP

desc: GROUPE ROTATIF

1шт.

1-1

K9002179

PISTON

desc: . PISTON

9шт.

1-2

K9002180

CYLINDER

desc: . CYLINDRES

1шт.

1-4

K9002181

PLATE;RETAINING

desc: . PLAQUE

1шт.

1-6

K9002182

BUCH;SPHERICAL

desc: . DOUILLE

1шт.

1-7

K9002183

SPRING

desc: . RESSORT

1шт.

1-9

K9002184

PIN;PRESSURE

desc: . GOUPILLE

3шт.

1-10

K9002185

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

1-11

K9002186

RING;BACK-UP

desc: . BAGUE D'ETANCHEITE

1шт.

5

-

HOUSING;PUMP

SC: D

1шт.

6

-

PLATE;PORT

SC: D

1шт.

7

K9002197

PLATE;SWASH

desc: PLATEUR OSCILLANT

1шт.

8

K9002198

SHAFT;DRIVE

desc: ARBRE MOTEUR

1шт.

12

K9002199

RING;RETAINING

desc: RONDELLE DE RETENUE

1шт.

15

K9002200

BEARING;TAPER ROLLER

desc: ROULEMENT A ROULEAUX CONIQUES

1шт.

16

K9002201

BEARING;TAPER ROLLER

desc: ROULEMENT A ROULEAUX CONIQUES

1шт.

17

K9002202

PLATE

desc: PLAQUE

2шт.

20

K9002203

SEAL;OIL

desc: JOINT D'HUILE

1шт.

22

K9002204

O-RING

desc: JOINT TORIQUE

1шт.

23

K9002205

O-RING

desc: JOINT TORIQUE

4шт.

25

K9002206

RING;RETAINING

desc: RONDELLE DE RETENUE

1шт.

27

K9002207

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

4шт.

30

K9002209

PLUG;SOCKET

desc: BOUCHON

1шт.

33

K9002210

PIN;CYLINDER

desc: GOUPILLE CYLINDRIQUE

1шт.

37

K9002187

PLATE;VALVE

desc: PLAQUE

1шт.

38

K9002189

PISTON;CONTROL

desc: PISTON DE COMMANDE

1шт.

39

K9002190

GUIDE;PISTON

desc: GUIDE DE PISTON

1шт.

40

K9002191

PISTON

desc: PISTON

1шт.

41

K9002192

GUIDE;PISTON

desc: GUIDE DE PISTON

1шт.

42

K9002193

SPRING

desc: RESSORT

1шт.

43

K9002194

SLEEVE;STOP

desc: MANCHON

1шт.
