Запчасти Doosan Daewoo ARM RAISE KICK OUT ASSY FRONT PARTS

-

K1004536A

ARM RAISE KICK OUT

SC: D

-2шт.

1

191-01489

PLATE

desc: PLAQUE

1шт.

2

K1004357

PLATE

desc: PLAQUE

1шт.

3

191-01453

PLATE

desc: PLAQUE

1шт.

4

4159-4008

COVER

desc: COUVERCLE

1шт.

5

4549-1148

SWITCH;PROXIMITY

SERIAL: 5001-5244

1шт.

5

K1027017

SWITCH;PROXIMITY

SERIAL: 5245

1шт.

6

S0509066

BOLT

desc: BOULON A 6 PANS

8шт.

7

S5102503

WASHER;SPRING

desc: RONDELLE ELASTIQUE M8

8шт.

8

S4012533

NUT

desc: ECROU

2шт.

9

2114-1058D29

WASHER;PLAIN

desc: RONDELLE

2шт.
