Запчасти Doosan Daewoo TIMING GEAR CASE ENGINE PARTS

1

K9002441

SCREW

desc: VIS

13шт.

2

K9002447

SCREW

desc: VIS

11шт.

3

K9002464

NUT;LOCK

desc: ECROU

5шт.

4

K9003970

OIL SEAL ASS'Y

desc: JOINT

1шт.

5

K9002472

CARRIER;SEAL

desc: PORTEUR

1шт.

6

K9003971

COVER;GEAR

desc: COUVERCLE

1шт.

7

K9002419

SCREW

desc: VIS

1шт.

8

K9002445

SCREW

desc: VIS

3шт.

9

K9002482

SCREW

desc: VIS

2шт.

10

K9002489

GASKET;GEAR HOUSING

desc: JOINT

1шт.

11

K9002506

HOUSING;GEAR

desc: BOITIER

1шт.

12

K9002584

PLUG;GEAR HOUSING

desc: BOUCHON

1шт.

13

-

PLUG

SC: D

1шт.

14

K9002631

O-RING

desc: . JOINT TORIQUE

1шт.

15

K9002317

CAP;FILLER

desc: CHAPEAU

1шт.

16

K9002377

SCREW

desc: VIS

2шт.

17

K9002465

TUBE;OIL FILLER

desc: TUBE

1шт.

18

K9002468

GASKET;HYDRAULIC PUMP

desc: JOINT

1шт.
