OIL PUMP & OIL PAN

Запчасти Doosan Daewoo OIL PUMP & OIL PAN ENGINE PARTS

1
23
32
12
15
16
14
26
30
2
16
17
31
22
11
24
33
25
10
13
19
21
20
18
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

K9002628

PUMP;LUBRICATING OIL

desc: POMPE

1шт.

2

K9002374

SCREW;HEXAGON HEAD CAP

desc: VIS

4шт.

10

K9002323

PLUG;PIPE

desc: BOUCHON

1шт.

11

K9002369

SCREW

desc: VIS

2шт.

12

K9002383

SCREW

desc: VIS

1шт.

13

K9002388

WASHER;SEALING

desc: RONDELLE

1шт.

14

K9002402

NUT

desc: ECROU

1шт.

15

K9002416

WASHER;PLAIN

desc: RONDELLE

1шт.

16

K9002419

SCREW

desc: VIS

2шт.

17

K9002466

GASKET;OIL SUC CONNECTION

desc: JOINT

1шт.

18

K9002410

SCREW

desc: VIS

32шт.

19

K9002428

WASHER;SEALING

desc: RONDELLE

1шт.

20

K9002434

PLUG;THREADED

desc: BOUCHON

1шт.

21

K9002435

PLUG;THREADED

desc: BOUCHON

1шт.

22

K9002448

SPACER;MOUNTING

desc: ENTRETOISE

2шт.

23

K9002449

BRACKET;TUBE

desc: CROISILLON

1шт.

24

K9002608

GASKET;OIL PAN

desc: JOINT

1шт.

25

K9002610

PAN;OIL

desc: CARTER MOTEUR

1шт.

26

K9002488

CONNECTION;OIL SUCTION

desc: RACCORDEMENT

1шт.

30

K9002587

DIPSTICK

desc: MESURE

1шт.

31

K9002523

TUBE;OIL GAUGE

desc: . TUBE

1шт.

32

K9002586

DIPSTICK

desc: . JAUGEUR

1шт.

33

K9002481

PLUG;EXPANSION

desc: BOUCHON

1шт.
