Запчасти Doosan Daewoo HEAD COVER & BREATHER ENGINE PARTS

1

K9002372

SCREW

desc: VIS

7шт.

2

K9002573

VALVE;COVER SUB ASS'Y

desc: VANNE

1шт.

3

K9002596

VALVE;COVER ASS'Y

desc: . VANNE

1шт.

4

K9002453

SCREW;TAPPING

desc: .. VIS

3шт.

5

-

COVER;VALVE

SC: D

1шт.

6

-

BAFFLE;BREATHER

SC: D

1шт.

7

K9002577

CAP;FILLER ASS'Y

desc: . CHAPEAU

1шт.

8

-

CAP;FILLER

SC: D

1шт.

9

K9002627

O-RING

desc: .. JOINT TORIQUE

1шт.

10

K9002530

GASKET;VALVE COVER

desc: . JOINT

1шт.

11

K9002531

ISOLATOR;NOISE

desc: ISOLANT

8шт.

20

K9002366

NUT

desc: ECROU

1шт.

21

K9002383

SCREW

desc: VIS

2шт.

22

K9002441

SCREW

desc: VIS

1шт.

23

K9002537

HOUSING;BREATHER

desc: LOGEMENT DE RENIFLARD

1шт.

24

K9002330

O-RING

desc: . JOINT TORIQUE

1шт.

25

-

HOUSING;BREATHER

SC: D

1шт.

26

K9002614

TUBE;LUB OIL DRAIN

desc: TUBE

1шт.
