FUEL FLOW SYSTEM (2)

Запчасти Doosan Daewoo FUEL FLOW SYSTEM (2) ENGINE PARTS

9
4
1
10
7
3
2
6
3
2
8
5
30
29
28
2
14
3
13
16
18
24
27
42
41
43
12
26
22
15
45
11
22
26
25
20
23
44
17
40
21
26
22
46
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

K9002606

HIGH PRESSURE PUMP ASS'Y

desc: POMPE

1шт.

2

K9002536

WASHER;SEALING

desc: . RONDELLE

3шт.

3

K9002590

CONNECTION;ADAPTER

desc: . RACCORDEMENT

3шт.

4

-

PUMP;FUEL

SC: D

1шт.

5

-

BODY;FUEL PUMP

SC: D

1шт.

6

-

PUMP;FUEL

SC: D

1шт.

7

K9002641

HEAD;FUEL PUMP

desc: .. TETE

1шт.

8

K9002642

GASKET;COVER PLATE

desc: .. JOINT

1шт.

9

K9002645

ADAPTER;FUEL PUMP

desc: .. ADAPTEUR

1шт.

10

K9002646

GASKET;FUEL PUMP

desc: .. JOINT

1шт.

11

K9002360

O-RING

desc: JOINT TORIQUE

1шт.

12

K9002387

SCREW

desc: VIS

1шт.

13

K9002390

NUT

desc: ECROU

4шт.

14

K9002399

SCREW

desc: VIS

1шт.

15

K9002444

SEAL;RECTANGULAR RING

desc: JOINT

1шт.

16

K9002460

STUD

desc: GOUJON

4шт.

17

K9002474

GEAR;FUEL PUMP

desc: GEAR;HELICAL

1шт.

18

K9002625

SUPPORT;FUEL PUMP

desc: SUPPORT

1шт.

20

K9002441

SCREW

desc: VIS

1шт.

21

K9002517

CLAMP;TUBE

desc: COLLIER

3шт.

22

K9002536

WASHER;SEALING

desc: RONDELLE

2шт.

23

K9002555

TUBE;FUEL SUPPLY

desc: TUBE

1шт.

24

K9003978

TUBE;FUEL SUPPLY

desc: TUBE

1шт.

25

K9002566

BRACE;TUBE

desc: CROISILLON

1шт.

26

K9002590

CONNECTION;ADAPTER

desc: RACCORDEMENT

3шт.

27

K9002331

SCREW

desc: VIS

2шт.

28

K9002386

SCREW

desc: VIS

2шт.

29

K9002550

SUPPORT;FILTER

desc: SUPPORT

1шт.

30

K9002604

SCREW

desc: VIS

2шт.

40

K9002620

FUEL FILTER ASS'Y

desc: ENSEMBLE FILTRE A GAZOLE

1шт.

41

K9002350

PLUG;THREADED

desc: . BOUCHON

2шт.

42

-

PLUG;THREADED

SC: D

1шт.

43

K9002351

O-RING

desc: .. JOINT TORIQUE

1шт.

44

K9002529

ADAPTER;FILTER HEAD

desc: . ADAPTATEUR

1шт.

45

-

HEAD;FUEL FILTER

SC: D

1шт.

46

K1008143

FILTER;FUEL

desc: . FILTRE

1шт.
