Запчасти Doosan Daewoo FLY WHEEL HOUSING ENGINE PARTS

2

K9002398

PLUG;THREADED

desc: BOUCHON

1шт.

3

K9002412

PLUG;SCREW

desc: VIS

1шт.

4

K9002413

O-RING

desc: JOINT TORIQUE

1шт.

5

K9002798

REAR COVER ASS'Y

desc: COUVERCLE

1шт.

5-1

K9004194

COVER;REAR

SC: D

1шт.

6

K9003670

SEAL;OIL

desc: JOINT D'HUILE

1шт.

7

K9002361

SCREW;HEXAGON HEAD CAP

desc: VIS

2шт.

8

K9002418

SEAL;RECTANGULAR RING

desc: JOINT

1шт.

9

K9002629

SCREW

desc: VIS

8шт.

10

K9002467

GASKET;REAR COVER

desc: JOINT

1шт.

11

K9002425

SCREW

desc: VIS

12шт.

12

K9002799

HOUSING;FLYWHEEL

desc: BOITIER

1шт.

13

K9002438

PLATE;COVER

desc: PLAQUE

1шт.
