Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

1

K9002350

PLUG;THREADED

desc: BOUCHON

1шт.

2

-

PLUG;THREADED

SC: D

1шт.

3

K9002351

O-RING

desc: . JOINT TORIQUE

1шт.

4

K9002532

SCREW

desc: VIS

26шт.

5

K9002570

GASKET;CYLINDER HEAD

desc: JOINT DE CULASSE

1шт.

6

K9002649

CYLINDER HEAD SUB ASS'Y

desc: CULLASSE

1шт.

7

K9002363

COLLET;VALVE

desc: . BAGUE

48шт.

8

K9002483

SEAL;VALVE STEM

desc: . JOINT

12шт.

9

K9002493

RETAINER;VALVE SPRING

desc: . ARRETOIR

12шт.

10

K9002496

SPRING;VALVE

desc: . JOINT TORIQUE

12шт.

11

K9002512

SEAL;VALVE STEM

desc: . JOINT

12шт.

12

K9002588

VALVE;EXHAUST

desc: . SOUPAPE D'ECHAPPEMENT

12шт.

13

K9002589

CYLINDER HEAD ASS'Y

desc: . CULLASSE

1шт.

14

K9002324

PLUG

desc: .. BOUCHON

2шт.

15

K9002427

PLUG

desc: .. BOUCHON

18шт.

16

-

RING;VALVE (INTAKE)

SC: D

12шт.

17

K9002473

GUIDE;VALVE STEM

desc: .. GUIDE

24шт.

18

K9002499

PLUG

desc: .. BOUCHON

1шт.

19

K9002500

PLUG

desc: .. BOUCHON

2шт.

20

K9002501

PLUG

desc: .. BOUCHON

1шт.

21

K9002502

PLUG

desc: .. BOUCHON

6шт.

22

K9002575

RING;VALVE (EXHAUST)

desc: .. ARRETOIR

12шт.

23

-

HEAD;CYLINDER

SC: D

1шт.

24

K9002594

VALVE;INTAKE

desc: . VALVE DE PRISE

12шт.

25

K9002626

ROTATOR;VALVE

desc: . BRAS DE CULBUTEUR

12шт.

26

K9002650

SPRING;VALVE

desc: . JOINT TORIQUE

12шт.
