Запчасти Doosan Daewoo CRANK SHAFT & PISTON ENGINE PARTS

1

K9003972

FLY WHEEL ASS'Y

desc: VOLANT

1шт.

2

K9003973

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

3

K9002405

GEAR;RING

desc: . PIGNON

1шт.

4

K9002407

BUSHING

desc: DOUILLE

1шт.

5

K9002379

BOLT

desc: BOULON A 6 PANS

8шт.

6

K9002365

WASHER;PLAIN

desc: RONDELLE

8шт.

10

K9002548

CRANKSHAFT ASS'Y

desc: VILEBREQUIN

1шт.

11

-

CRANK SHAFT

SC: D

1шт.

12

K9002423

GEAR;CRANKSHAFT

desc: . PIGNON

1шт.

13

K9002400

PIN;DOWEL

desc: . GOUPILLE D'AJUSTAGE

1шт.

14

K9002507

BEARING KIT (STD)

desc: KIT DE PALIER

1шт.

14

K9002508

BEARING KIT (0.25MM)

SC: OS

1шт.

14

K9002509

BEARING KIT (0.50MM)

SC: OS

1шт.

15

-

BEARING;MAIN

SC: D

6шт.

16

-

BEARING;CRANKSHAFT THRUST

SC: D

1шт.

17

-

BEARING;MAIN

SC: D

7шт.

20

K9002443

REAR WEAR SLEEVE & SEAL KIT

desc: DOUILLE ARRIERE D'USAGE

1шт.

21

-

SEAL;OIL

SC: D

1шт.

22

-

SLEEVE;WEAR

SC: D

1шт.

23

K9002439

FRONT WEAR SLEEVE & SEAL KIT

desc: KIT DE JOINT

1шт.

24

-

SEAL;OIL

SC: D

1шт.

25

K9002437

SLEEVE;WEAR

desc: . DOUILLE

1шт.

26

-

SHIELD;DUST

SC: D

1шт.

30

K9002420

SCREW

desc: VIS

5шт.

31

K9002569

DAMPER;VIBRATION

desc: AMORTISSEUR DE VIBRATIONS

1шт.

32

K9002478

CRANKSHAFT PULLEY ASS'Y

desc: POULIE

1шт.

33

-

PULLEY;CRANKSHAFT

SC: D

1шт.

34

-

ADAPTER;CRANKSHAFT

SC: D

1шт.

40

K9002601

CONNECTING ROD ASS'Y

desc: BIELLE ASS'Y

6шт.

41

K9002572

CONNECTING ROD

desc: . BIELLE

1шт.

42

K9002495

BOLT

desc: . BOULON A 6 PANS

2шт.

43

K9002598

BUSHING

desc: . MANCHON

1шт.

44

K9002557

BEARING;CONNECTING ROD

desc: PALIER

6шт.

45

K9002515

BEARING;CONNECTING ROD

desc: PALIER

6шт.

46

K9002640

PISTON KIT

desc: KIT PISTON

6шт.

47

K9002426

RING;RETAINING

desc: . RONDELLE DE RETENUE

2шт.

48

-

SKIRT;PISTON

SC: D

1шт.

49

K9002613

TOP;PISTON

desc: . PISTON

1шт.

50

K9002638

SET;PISTON RING

desc: . ANNEAU DE PISTON

1шт.

51

K9002514

PIN;PISTON

desc: AXE DE PISTON

6шт.
