Запчасти Doosan Daewoo CONTROL VALVE CONTROL VALVE PIPING-3 SPOOL

-

K1003141

CONTROL VALVE

desc: VANNE DE COMMANDE

1шт.

1

K9002751

COUNTER PRESSURE VALVE 4.8 BAR

desc: REFROIDISSEUR

1шт.

2

K9002752

COVER

desc: COUVERCLE

1шт.

3

K9002753

CHECK VALVE

desc: CLAPET ANTI-RETOUR

4шт.

4

K9002754

SUPPLY CHECK VALVE

desc: CLAPET ANTI-RETOUR D'APPROVISIONNEMENT

2шт.

5

K9002755

COVER

desc: COUVERCLE

1шт.

6

K9002756

PLUG

desc: BOUCHON

1шт.

7

K9002757

PLUG N

desc: BOUCHON

1шт.

8

K9002758

RING

desc: BAGUE D'ETANCHEITE

1шт.

9

K9002759

CHECK VALVE

desc: CLAPET DE RETENUE

1шт.

10

K9002760

PRESSURE RELIEF VALVE

desc: SOUPAPE DE SECURITE

2шт.

11

K9002761

PRESSURE RELIEF VALVE

desc: SOUPAPE DE SECURITE

2шт.

12

K9002762

EYE;LIFTING

desc: OEIL

1шт.

13

K9002763

RING;SEALING

SC: K

4шт.

14

K9002764

PLUG

desc: BOUCHON

4шт.

15

K9002765

RING;SEALING

SC: K

1шт.

16

K9002766

PLUG

desc: BOUCHON

1шт.

17

K9002767

SERVO-SPOOL SUPPLY CHECK VALVE

desc: BOBINE SERVO

2шт.

18

K9002768

SEAL KIT;INTERSECTION

SC: K

1шт.

19

K9002769

SEAL KIT;BLOCK A

SC: K

1шт.

20

K9002770

SCREW

desc: VIS

4шт.

21

K9002763

RING;SEALING

SC: K

4шт.

22

K9002764

PLUG

desc: BOUCHON

4шт.

23

K9002771

SPRING PACKAGE 6-18 BAR

desc: RESSORT

2шт.

24

K9002767

SERVO-SPOOL SUPPLY CHECK VALVE

desc: BOBINE SERVO

1шт.

25

K9002772

CHECK VALVE

desc: CLAPET ANTI-RETOUR

1шт.

26

K9002773

FLOAT POSITION SPRINGS

desc: RESSORT

1шт.

27

K9002774

COVER

desc: COUVERCLE

1шт.

28

K9002843

SPOOL KIT

desc: KIT DE RESSORT

1шт.

29

K9002775

SEAL KIT;INTERSECTION

SC: K

1шт.

30

K9002776

SEAL KIT

SC: K

1шт.

31

K9002777

ORIFICE D0.6 (BROWN)

desc: ORIFICE

1шт.

32

K9002766

PLUG

desc: BOUCHON

8шт.

33

K9002778

SCREW

desc: VIS

2шт.

34

K9002779

SCREW

desc: VIS

2шт.

35

K9002754

VALVE;SUPPLY CHECK

desc: VANNE

2шт.

36

K9002780

VALVE;LOAD SIGNAL DRAINAGE

desc: VANNE

1шт.

37

K9002781

SEAL KIT INTERSECTION

SC: K

1шт.

38

K9002782

SCREW

desc: VIS

8шт.

39

K9002764

PLUG

desc: BOUCHON

1шт.

40

K9002844

SPOOL;BUCKET

desc: BOBINE

1шт.

41

K9002845

SPOOL;BOOM

desc: BOBINE

1шт.

*

K9002783

SEAL KIT

desc: KIT D'ETANCHEITE

1шт.
