Запчасти Doosan Daewoo STEERING UNIT HYDRAULIC PARTS

-

420-00418

STEERING UNIT

desc: UNITE

1шт.

1

2.115-00194

RING;DUST SEAL

SC: K

1шт.

2

HOUSING SPOOL & SLEEVE

SC: D

1шт.

3

2.148-00001

BALL

desc: BILLE

1шт.

4

2.408-00128

BUSHING;THREAD

desc: MANCHON

1шт.

5

2.180-00199

O-RING

SC: K

1шт.

7

2.109-00085

BEARING ASS'Y

desc: PALIER

1шт.

8

2.115-00080

RING

desc: BAGUE

1шт.

9

2.123-00129

PIN;CROSS

desc: GOUPILLE

1шт.

11

2.405-00086

CARDON SHAFT

desc: ARBRE

1шт.

12

K9002681

SET OF SPRINGS

desc: RESSORT

1шт.

13

2.180-00200

O-RING

SC: K

3шт.

14

2.412-00143

DISTRIBUTOR PLATE

desc: PLAT DE DISTRIBUTEUR

1шт.

15

K9002682

GEARWHEEL SET

desc: PIGNON

1шт.

17

2.430-00295

COVER;END

desc: COUVERCLE ARRIERE

1шт.

18

2.114-00806

WASHER

SC: K

7шт.

20

K9002683

SCREW WITH PIN

desc: VIS

1шт.

21

2.120-00483

SCREW

desc: VIS

6шт.

*

2.911-00060

SEAL KIT

desc: KIT DE REPARATION

1шт.
