/ / / / / PLANETARY GEAR - REAR AXLE
Запчасти Doosan Daewoo PLANETARY GEAR - REAR AXLE HYDRAULIC PARTS
281
252
160
282
250
270
20
30
80
180
50
40
150
30
50
210
10
90
400
120
110
130
100
60
70
10
K9000671
HOUSING;BRAKE
desc: CARTER
2шт.
20
K9000032
PLUG
desc: BOUCHON
2шт.
30
K9000179
O-RING
desc: JOINT TORIQUE
4шт.
40
K9000334
GEAR;RING
desc: PIGNON
2шт.
50
K9000176
O-RING
desc: JOINT TORIQUE
4шт.
60
K9000240
RING;MULTI SEAL
desc: ANNEAU
2шт.
70
K9000249
BEARING;TAPPER ROLLER
desc: ROULEMENT
2шт.
80
K9000672
BEARING;TAPPER ROLLER
desc: ROULEMENT
2шт.
90
K9002866
SHAFT;OUTPUT
desc: ARBRE
2шт.
100
K9000674
NUT;SLOTTED
desc: ECROU
2шт.
110
K9000173
PIN;SLOT
desc: GOUPILLE
2шт.
120
K9000286
COVER
desc: COUVERCLE
2шт.
130
2.180-00284
O-RING
desc: JOINT TORIQUE
2шт.
150
K9000337
SHAFT;SUN GEAR
desc: ARBRE
2шт.
160
K9000336
GEAR;PLANET
desc: PIGNON
6шт.
180
K9000675
CARRIER;PLANET
desc: PORTEUR DE PLANETE
2шт.
210
K9000277
BOLT;STOP
desc: BOULON
2шт.
250
K9000321
RING;BEARING INNER
desc: ANNEAU
6шт.
252
K9000322
RING;BEARING INNER
desc: ANNEAU
6шт.
270
K9000171
RING;RETAINING
desc: ANNEAU DE SOUTIEN
6шт.
281
K9000164
SCREW;PLUG
desc: VIS
2шт.
282
1.180-00137
O-RING
desc: JOINT TORIQUE
2шт.
400
K9002864
BOLT;WHEEL
desc: BOULON A 6 PANS
32шт.
