Запчасти Doosan Daewoo DRIVING SYSTEM ENGINE PARTS

10

65.02101-0064

SHAFT;CRANK

desc: ARBRE

1шт.

30

65.02130-0001

RING;WEAR(FRONT)

desc: SEGMENT D'USURE

1шт.

40

06.22022-1018

PIN;DOWEL 8M6X45

desc: GOUJON

1шт.

50

65.02115-0014B

GEAR;CRANK SHAFT

desc: PIGNON

1шт.

70

65.01505-0007

RING;OIL THROWER

desc: BAGUE

1шт.

100

65.01110-6120

BEARING;MAIN

desc: PALIER

7шт.

110

65.01110-6121

BEARING;MAIN (0.25)

SC: US

7шт.

111

65.01110-6122

BEARING;MAIN (0.50)

SC: US

7шт.

200

65.01150-0015

WASHER;THRUST(UPPER)

desc: RONDELLE DE BUTEE(HAUT) STD

2шт.

210

65.01150-0019

WASHER;THRUST(0.25)

SC: OS

1шт.

220

65.01150-0020

WASHER;THRUST(0.50)

SC: OS

1шт.

250

65.01150-0016A

WASHER;THRUST(LOWER)

desc: RONDELLE DE BUTEE

2шт.

260

65.01150-0023A

WASHER;THRUST(0.25)

SC: OS

1шт.

270

65.01150-0024A

WASHER;THRUST(0.50)

SC: OS

1шт.

310

65.02201-7032

DAMPER;VISCOUS(ALT)

SC: D

1шт.

321

65.02201-7033

DAMPER;VISCOUS

desc: . DAMPER;VISCOUS

1шт.

330

65.02201-7034

DAMPER;VISCOUS

desc: . DAMPER;VISCOUS

1шт.

340

65.90020-0062B

BOLT;HEX. M10X20

desc: BOULON A 6 PANS

6шт.

410

65.02301-5145A

FLYWHEEL

desc: VOLANT

1шт.

420

65.02301-0289A

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

430

65.02310-0073D

GEAR;STARTER RING

desc: . PIGNON

1шт.

450

65.02130-0003

BUSH;DRIVING

desc: BUSH;DRIVING

1шт.

460

65.90701-0096

WASHER

desc: RONDELLE

1шт.

470

65.90020-0108

BOLT;COLLARED HEX

desc: BOULON A 6 PANS

8шт.

510

65.02401-6025

ROD;CONNECTING

SERIAL: 060602

6шт.

510

65.02401-6025A

ROD;CONNECTING

SERIAL: 060603

6шт.

520

65.02401-0013

ROD;CONNECTING

SERIAL: 060602

1шт.

520

65.02401-0013A

ROD;CONNECTING

SERIAL: 060603

1шт.

540

65.90020-0009D

BOLT;CONNECTING ROD

desc: . VIS DE BIELLE

2шт.

550

65.02405-0007

BUSH;CONNECTING ROD

SERIAL: 060602

1шт.

550

65.02405-0010

BUSH;CONNECTING ROD

SERIAL: 060603

1шт.

560

65.91301-0010

PIN;DOWEL

desc: . GOUPILLE D'AJUSTAGE

2шт.

570

65.02410-6130

BEARING;CONNECTING ROD

desc: BEARING;CONNECTING

6шт.

580

65.02410-6131

BEARING;CON. ROD(0.25)

SC: US

1шт.

590

65.02410-6132

BEARING;CON. ROD(0.50)

SC: US

1шт.

610

65.02501-0501

PISTON

desc: PISTON

6шт.

630

65.02503-0127

RING;PISTON

desc: BAGUE

6шт.

640

65.02503-0128

RING;PISTON

desc: BAGUE

6шт.

650

65.02503-0129

RING;PISTON

desc: BAGUE

6шт.

660

65.02502-0015

PIN;PISTON

desc: GOUJON

6шт.

670

65.90815-0024A

RING;LOCK

desc: BAGUE

12шт.

710

65.02601-0219

PULLEY;V-BELT

desc: POULIE

1шт.

720

06.02106-0824

BOLT

desc: BOULON A 6 PANS

8шт.
