Запчасти Doosan Daewoo BREATHER PIPE ENGINE PARTS

10

65.01801-5039

HOUSING;BREATHER

SERIAL: 060518

1шт.

20

06.01923-3118

BOLT ASS'Y M8X35

desc: BOULON 6 PANS

4шт.

30

65.96301-0399

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

40

06.67020-0101

CLAMP;HOSE

desc: ATTACHE

2шт.

50

65.98131-0097

NIPPLE

desc: MAMELON

1шт.

60

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

1шт.

100

65.01802-5034

PIPE;BREATHER

desc: PIPE;BREATHER

1шт.

120

06.16731-2108

WASHER;SPRING A10

desc: RONDELLE

2шт.

130

06.11063-8215

NUT M10

desc: ECROU 6 PANS M10

2шт.

200

65.96301-0420

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

220

06.67020-0105

CLAMP NWS16

desc: COLLIER

2шт.

420

65.96301-0438

HOSE;RUBBER

desc: TUYAU FLEXIBLE

1шт.

430

06.67020-0105

CLAMP NWS16

desc: COLLIER

1шт.

440

65.90201-0122

BOLT;STUD

desc: BOULON A 6 PANS

1шт.

450

65.97401-5019

CLIP;PIPE

desc: ATTACHE

1шт.

460

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

1шт.

470

06.11063-8214

NUT M8

desc: ECROU 6 PANS M8

1шт.
