Запчасти Doosan Daewoo BRAKE - REAR AXLE HYDRAULIC PARTS

-

211-00066

AXLE;REAR

desc: AXE

1шт.

1

2.120-00010

BOLT;ADJUSTING

desc: VIS DE REGLAGE

6шт.

2

2.131-00002

SPRING

desc: RESSORT

6шт.

3

2.180-00217

O-RING

desc: JOINT AR

6шт.

4

2.121-00005

NUT

desc: ECROU

6шт.

5

2.222-00012

DISC;BRAKE

desc: DISQUE DE FREIN

8шт.

6

2.222-00013

DISC;BRAKE

desc: DISQUE DE FREIN

8шт.

7

2.180-00213

O-RING

desc: JOINT OR

6шт.

8

2.180-00914

RING;BACK-UP

desc: BAUGE ANTIEXTRUSION

6шт.

9

2.409-00002

PISTON

desc: PISTON

6шт.

10

2.222-00004

DISC

desc: DISQUE

1шт.

11

2.222-00005

DISC

desc: DISQUE

1шт.

12

2.181-00113

PLUG

desc: BOUCHON

2шт.

13

2.120-00176

BOLT;BLEEDING

desc: VIS DE PURGE

2шт.
