Запчасти Doosan Daewoo STEERING UNIT HYDRAULIC PARTS

-

4420-9555

UNIT;STEERING

desc: ORBITROL

1шт.

1

2.115-00194

RING;DUST SEAL

desc: BAGUE

1шт.

2

-

HOUSING SPOOL

SC: D

1шт.

3

2.148-00001

BALL

desc: BILLE

1шт.

4

2.408-00128

BUSHING;THREAD

desc: MANCHON

1шт.

5

2.180-00199

O-RING

desc: JOINT TORIQUE

1шт.

6

2.109-00085

BEARING ASS'Y

desc: PALIER

1шт.

7

2.115-00080

RING

desc: BAGUE

1шт.

8

2.123-00129

PIN;CROSS

desc: BROCHE

1шт.

9

2.131-00500

SET OF SPRINGS

desc: VIS DE REGLAGE

1шт.

10

2.405-00086

SHAFT;CARDON

desc: TOURNEVIS EN CROIX

1шт.

12

2.180-00200

O-RING

desc: JOINT TORIQUE

1шт.

13

2.412-00172

PLATE;INTERMEDIATE

desc: INTERMEDIATE PLATE

1шт.

14

2.180-00201

O-RING

desc: JOINT TORIQUE

3шт.

15

2.412-00143

PLATE;PISTRIBUTOR

desc: PLAQUE

1шт.

16

2.403-00292

GEARWHEEL SET

desc: ENSEMBLE DE PIGNON

1шт.

17

2.430-00295

COVER;END

desc: COUVERCLE

1шт.

18

2.114-00806

WASHER

desc: RONDELLE

7шт.

20

2.120-00505

SCREW WITH PIN

desc: VIS

1шт.

21

2.120-00371

SCREW

desc: VIS

6шт.

24

2.421-00229

COMPLETE RELIEF VALVE

desc: CLAPET DE DECHARGE

1шт.

25

2.911-00060

SPARE KIT

desc: KIT DE REPARATION

1шт.

26

2.180-00607

SET OF O-RINGS

desc: VIS DE REGLAGE

1шт.

27

2.123-00018

PIN

desc: BROCHE

1шт.

28

2.120-00372

SCREW

desc: VIS

2шт.

29

2.421-00287

VALVE;SHOCK

desc: SOUPAPE

2шт.

30

2.131-00018

SPRING

desc: RESSORT

2шт.

31

2.180-00269

O-RING

desc: JOINT TORIQUE

2шт.

32

2.181-00134

PLUG

desc: BOUCHON

2шт.

33

-

HOUSING

SC: D

1шт.
