Запчасти Doosan Daewoo PLANETARY GEAR - REAR AXLE HYDRAULIC PARTS

-

211-00066

AXLE;REAR

desc: AXE

1шт.

1

2.181-00110

PLUG

desc: BOUCHON

2шт.

3

2.423-00028

CASE;AXLE

desc: CORQS D'ESSIEU

2шт.

4

2.180-00670

SEAL

desc: JOINT D'ETANCHEITE

2шт.

5

2.115-00191

RING;CENTERING

desc: BAGUE DE CENTRAGE

2шт.

6

2.317-00076

STUD;WHEEL

desc: GOUJON DE ROUE

24шт.

7

2.219-00023

HUB;WHEEL

desc: MOYEU DE ROUE

2шт.

8

2.121-00003

NUT

desc: ECROU

24шт.

9

2.120-00018

BOLT;HEX

desc: VIS A TETE EXAGONALE

10шт.

10

2.405-00136

SHAFT;HALF

desc: DEMI ARBRE

2шт.

11

2.115-00339

RING;SNAP

desc: BAGUE D'ARRET

12шт.

12

2.114-00809

WASHER;FRICTION

desc: RONDELLE

12шт.

13

2.123-00005

PIN

desc: AXE

6шт.

14

2.180-00208

O-RING

desc: JOINT OR

6шт.

15

2.217-00049

CARRIER;PLANET GEAR

desc: SUPPORT SATELLITES

2шт.

16

2.181-00385

PLUG;MAGNET

desc: BOUCHON MAGNETIQUE

2шт.

17

2.120-00005

BOLT;CYLINDER

desc: VIS A TETE CYLINDRIQUE

4шт.

18

2.114-00810

WASHER;FRICTION

desc: RONDELLE

2шт.

19

2.123-00140

DOWEL

desc: BROCHE ELASTIQUE

6шт.

20

2.109-00160

BEARING;NEEDLE

desc: ROULEMENT A AIGUILLE

6шт.

21

2.403-00184

GEAR;PLANET

desc: SATELLITE

6шт.

22

2.412-00181

PLATE;LOCKING

desc: TOLE DE SECURITE

6шт.

23

2.120-00245

BOLT;HEX

desc: VIS A TETE EXAGONALE

12шт.

24

2.412-00187

PLATE;LOCKING

desc: TOLE DE SECURITE

2шт.

25

2.197-00052

SUPPORT;RING GEAR

desc: SUPPORT PORTE COURONNE

2шт.

26

2.123-00259

DOWEL

desc: BROCHE ELASTIQUE

10шт.

27

2.115-00340

RING;SNAP

desc: BAGUE D'ARRET

2шт.

28

2.403-00223

GEAR;RING

desc: COURONNE DENTEE

2шт.

29

2.180-00265

O-RING

desc: JOINT OR

2шт.

30

2.109-00235

BEARING;TAPER ROLLER

desc: ROULEMENT A R. CONIQUES

4шт.

31

K9004352

SEAL

desc: JOINT D'ETANCHEITE

2шт.
