Запчасти Doosan Daewoo PLANETARY GEAR - FRONT AXLE HYDRAULIC PARTS

-

211-00065

AXLE;FRONT

desc: AVANT

1шт.

1

2.317-00076

STUD;WHEEL

desc: GOUJON DE ROUE

24шт.

2

2.180-00265

O-RING

desc: JOINT OR

2шт.

3

2.120-00004

BOLT

desc: VIS

20шт.

5

2.114-00809

WASHER;FRICTION

desc: RONDELLE

6шт.

6

2.403-00185

GEAR;PLANET

desc: SATELLITE

6шт.

7

2.109-00160

BEARING;NEEDLE

desc: ROULEMENT A AIGUILLE

6шт.

8

2.217-00048

CARRIER;PLANET GEAR

desc: SUPPORT SATELLITES

2шт.

9

2.121-00003

NUT

desc: ECROU

24шт.

10

2.181-00385

PLUG;MAGNET

desc: BOUCHON MAGNETIQUE

2шт.

11

2.123-00017

PIN

desc: AXE

6шт.

12

2.180-00266

O-RING

desc: JOINT OR

6шт.

13

2.120-00005

BOLT;CYLINDER

desc: VIS A TETE CYLINDRIQUE

4шт.

14

2.114-00810

WASHER;FRICTION

desc: RONDELLE

2шт.

15

2.124-00046

CIRCLIP

desc: ARRETOIR

2шт.

16

2.403-00224

GEAR;RING

desc: COURONNE DENTEE

2шт.

17

2.109-00235

BEARING;TAPER ROLLER

desc: ROULEMENT A R . CONIQUES

4шт.

18

2.219-00023

HUB;WHEEL

desc: MOYEU DE ROUE

2шт.

19

K9004352

SEAL

desc: JOINT D'ETANCHEITE

2шт.

20

2.115-00191

RING;CENTERING

desc: BAGUE DE CENTRAGE

2шт.

21

2.180-00670

SEAL

desc: JOINT D'ETANCHEITE

2шт.

22

2.423-00029

CASE;AXLE

desc: CORPS D'ESSIEU

2шт.

23

2.405-00135

SHAFT;HALF

desc: DEMI ARBRE

2шт.

25

2.408-00119

BUSHING;REDUCTION

desc: MANCHON DE REDUCTION

20шт.

28

2.412-00182

PLATE;LOCKING

desc: TOLE DE SECURITE

2шт.
