GEAR SHIFT SYSTEM(2) - TRANSMISSION

Запчасти Doosan Daewoo GEAR SHIFT SYSTEM(2) - TRANSMISSION HYDRAULIC PARTS

390
380
370
360
350
362
30
40
20
10
40
30
170
280
300
290
181
180
200
190
160
150
50
60
90
110
12
13
210
250
230
310
330
340
320
270
241
240
260
220
50
60
80
70
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

10

1.451-00082

BLOCK;VALVE

desc: BLOC-VALVES

1шт.

12

1.120-00165

PLUG

desc: BOUCHON

8шт.

13

180-00408

O-RING

desc: JONT TORIQUE

8шт.

20

1.415-00001

ORIFICE

desc: AJUTAGE

6шт.

30

1.409-00006

PISTON

desc: PISTON

6шт.

40

1.131-00004

SPRING;COMPR

desc: RESSORT

6шт.

50

1.409-00007

PISTON

desc: PISTON

6шт.

60

1.131-00005

SPRING;COMPR

desc: RESSORT

6шт.

70

1.409-00008

PISTON

desc: PISTON

1шт.

80

1.131-00006

SPRING;COMPR

desc: RESSORT

1шт.

90

K9000101

PISTON;CONTROL

desc: PISTON REGLAGE

1шт.

110

1.131-00007

SPRING;COMPR

desc: RESSORT

1шт.

150

K9000115

GASKET

desc: GARNITURE

1шт.

160

2.402-00304

HOUSING

desc: CARTER

1шт.

170

1.120-00057

SCREW

desc: VIS

18шт.

180

1.421-00001

REGULATOR;PRESSURE

desc: REGULULATOR PRESSION

3шт.

181

1.180-00057

O-RING

desc: . JONT TORIQUE

3шт.

190

1.412-00004

PLATE;FIXING

desc: COUVERCLE

3шт.

200

1.120-00086

SCREW

desc: VIS

3шт.

210

K9000115

GASKET

desc: GARNITURE

1шт.

220

2.402-00304

HOUSING

desc: CARTER

1шт.

230

1.120-00057

SCREW

desc: VIS

18шт.

240

1.421-00001

REGULATOR;PRESSURE

desc: REGULULATOR PRESSION

3шт.

241

1.180-00057

O-RING

desc: . JONT TORIQUE

3шт.

250

1.412-00004

PLATE;FIXING

desc: COUVERCLE

3шт.

260

1.120-00086

SCREW

desc: VIS

3шт.

270

1.530-00001

HARNESS;WIRING

desc: FAISCEAU

1шт.

280

K9000109

GASKET

desc: GARNITURE

1шт.

290

1.430-00002

COVER

desc: COUVERCLE

1шт.

300

1.120-00057

SCREW

desc: VIS

14шт.

310

K9000109

GASKET

desc: GARNITURE

1шт.

320

1.430-00003

COVER

desc: COUVERCLE

1шт.

330

1.124-00141

CLAMP;RETAINING

desc: ETRIER RETENUE

1шт.

340

1.120-00057

SCREW

desc: VIS

14шт.

350

1.180-00007

GASKET

desc: GARNITURE

1шт.

360

K9002920

SHEET;INTERMEDIATE

desc: TOLE INTERM.

1шт.

362

1.471-00007

SCREEN

desc: TAMIS

6шт.

370

1.180-00008

GASKET

desc: GARNITURE

1шт.

380

K9000100

PLATE;DUCT

desc: PLAQUE CANIVEAU

1шт.

390

1.120-00087

SCREW M6X23

desc: VIS

18шт.
