Запчасти Doosan Daewoo TIMING SYSTEM ENGINE PARTS

1

65.04101-0065B

VALVE;INTAKE

desc: SOUPAPE D'ADMISSION

12шт.

2

65.04101-0066B

VALVE;EXHAUST

desc: VANNE

12шт.

3

65.04102-0024

SPRING;VALVE

desc: JOINT TORIQUE

24шт.

4

65.04103-0018

PLATE;VALVE SPRING

desc: PLAQUE

24шт.

5

65.90701-0098

WASHER

desc: CALE

24шт.

6

65.04104-0009

COTTER;VALVE

desc: COTTER;VALVE

48шт.

7

65.04902-0016

SEAL;VALVE STEM

desc: JOINT

24шт.

8

65.04130-0009A

CALIPER (INTAKE)

desc: ETRIER

6шт.

9

65.04130-0011

CALIPER (EXHAUST)

desc: ETRIER

6шт.

10

65.04200-6038A

ROCKER ARM S/F ASS'Y

SERIAL: 061213

2шт.

10

65.04200-6038B

ROCKER ARM S/F ASS'Y

SERIAL: 061214

2шт.

11

65.04201-5042A

ROCKER ARM;INTAKE

SERIAL: 061213

3шт.

11

65.04201-5042B

ROCKER ARM;INTAKE

SERIAL: 061214

3шт.

12

65.04201-5043A

ROCKER ARM;EXHAUST

SERIAL: 061213

3шт.

12

65.04201-5043B

ROCKER ARM;EXHAUST

SERIAL: 061214

3шт.

13

65.04203-5020A

SHAFT;ROCKER ARM

desc: . AXE DU CULBUTEUR

1шт.

14

65.04202-0033

BRACKET;ROCKER ARM

desc: . SUPPORT

1шт.

15

65.04202-0034

BRACKET;ROCKER ARM

desc: . SUPPORT

1шт.

16

65.04202-0035

BRACKET;ROCKER ARM

desc: . SUPPORT

2шт.

17

65.97601-0124

SPRING;COMPESSION

desc: . RESSORT

3шт.

18

65.90701-0136B

WASHER

desc: . RONDELLE

6шт.

19

06.29010-0120

RING;SNAP

desc: . CIRCLIP

2шт.

20

65.90030-0018

BOLT;SOCKET

desc: . BOULON

1шт.

21

06.16110-0106

WASHER

desc: . RONDELLE

1шт.

22

65.04205-0014

SCREW;ADJUST

desc: . VIS

6шт.

23

65.90501-0003

NUT

desc: . ECROU 6 PANS

6шт.

24

65.04209-0005

CAP;ADJUST SCREW (INTAKE)

desc: . CHAPEAU

3шт.

25

65.04209-0006

CAP;ADJUST SCREW (EXHAUST)

desc: . CHAPEAU

3шт.

26

65.90020-0120

BOLT;COLLARED HEX

desc: . BOULON A 6 PANS

8шт.

30

65.04301-5003B

TAPPET;VALVE

desc: TRINGLERIE

12шт.

31

65.04302-5015

ROD;PUSH

desc: POUSSOIR

12шт.

32

65.04401-0045A

CAMSHAFT

desc: EQUIPAGE MOBILE

1шт.

33

06.22022-1016

PIN;DOWEL

desc: GOUPILLE

1шт.

34

65.90720-0032

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

35

06.01913-2911

BOLT

desc: BOULON

2шт.

40

65.04501-0017

GEAR;CAM SHAFT

desc: PIGNON

1шт.

41

65.90020-0117

BOLT

desc: BOULON

4шт.

42

65.04505-5018

GEAR;IDLE

desc: PIGNON

1шт.

43

65.04506-0016

PIN;IDLE GEAR

desc: GOUPILLE

1шт.

44

65.90720-0034B

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

45

65.90020-0118

BOLT

desc: BOULON

3шт.

46

65.11301-5002

GEAR;DRIVE;INJECTION

desc: PIGNON

2шт.

47

65.04506-0015

PIN;IDLE GEAR

desc: GOUPILLE

2шт.

48

65.90720-0033A

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

49

65.90020-0118

BOLT

desc: BOULON

1шт.

50

65.90020-0119

BOLT

desc: BOULON

1шт.
