Запчасти Doosan Daewoo OIL PAN ENGINE PARTS

1

65.05801-5249

PAN;OIL

desc: CARTER MOTEUR

1шт.

4

65.05904-0035

GASKET;OIL PAN

desc: JOINT

1шт.

5

06.01923-3120

BOLT

desc: BOULON A 6 PANS

22шт.

6

65.05806-5005

TUBE;OIL LEVEL GAUGE

desc: TUBE

1шт.

7

65.05805-5238

OIL LEVEL GAUGE

desc: INDICATEUR DE NIVEAU D'HUILE

1шт.

8

65.05701-6122

OIL PIPE ASS'Y

desc: CONDUITES DE HUILE

1шт.

10

65.05740-0222

BRACKET;OIL SUCT. PIPE

desc: . SUPPORT

1шт.

11

65.97401-0137

CLIP;PIPE

desc: . ATTACHE

1шт.

12

06.01283-7115

BOLT

desc: . BOULON A 6 PANS

1шт.

13

06.15010-2311

WASHER

desc: . RONDELLE

1шт.

14

65.90510-0012

NUT

desc: . ECROU 6 PANS M10x1.0

1шт.

15

65.05901-0032

GASKET

desc: JOINT

1шт.

16

06.01913-3115

BOLT

desc: BOULON A 6 PANS

1шт.

17

06.01913-3119

BOLT

desc: BOULON A 6 PANS

2шт.

30

65.96340-6015

DRAIN HOSE ASS'Y

desc: TUYAU FLEXIBLE

1шт.

31

65.96340-5013A

HOSE;DRAIN

desc: . TUYAU FLEXIBLE

1шт.

32

65.98130-0203

ADAPTER

desc: . ADAPTEUR

1шт.

33

65.98125-5004A

COCK;DRAIN

desc: . ROBINET DE PURGE

1шт.

34

06.56190-0732

RING;SEAL A30X36

desc: BAGUE D'ETANCHEITE

1шт.

35

65.01813-5019

PIPE;OIL FILLER

desc: TUYAU

1шт.

36

65.05903-0029A

GASKET

desc: JOINT

1шт.

37

06.01913-3114

BOLT

desc: BOULON A 6 PANS

4шт.

38

65.01810-5011

CAP;OIL FILLER

desc: VIBREUR

1шт.
