Запчасти Doosan Daewoo TRACK LINK-DOMESTIC UNDER STRUCTURE

-

5604-1193

TRACK ASS'Y

SC: D

-2шт.

9

5272-9031B

TRACK LINK ASS'Y

desc: ARTICULATION

2шт.

9-1

5272-6109A

LINK;TRACK(R.H.)

desc: . ARTICULATION

39шт.

9-2

5272-6189

LINK;TRACK(L.H.)

desc: . ARTICULATION

39шт.

9-3

5123-6065

PIN;TRACK

desc: . GOUPILLE

38шт.

9-5

5110-6057A

BUSHING;TRACK

desc: . DOUILLE

38шт.

9-4

5123-6064

PIN;MASTER

desc: . BROCHE PRINCIPALE

1шт.

9-6

5110-6056A

BUSHING;MASTER

desc: . DOUILLE

1шт.

9-7

5180-6083

DUST SEAL

desc: . RACCORD ADAPTATEUR

76шт.

9-8

5180-6084

DUST SEAL;MASTER

desc: . RACCORD ADAPTATEUR

2шт.

47

5273-1035C

SHOE 765mm

desc: SABOT

78шт.

48

5120-1441C

BOLT;SHOE

desc: BOULON A 6 PANS

312шт.

49

5121-1274A

NUT;SHOE

desc: ECROU

312шт.

53

S5102801

WASHER;SPRING M14

desc: RONDELLE ELASTIQUE

312шт.

57

2195-2527D13

BRACKET

SERIAL: 113-323

2шт.

58

S0515353

BOLT M12X1.75X30

SERIAL: 113-323

8шт.

58

S0514853

BOLT M12X1.75X20

SERIAL: 324

8шт.
