Запчасти Doosan Daewoo LOWER ROLLER-D.F UNDER STRUCTURE

-

5604-1237A

TRACK ASS'Y

SC: D

-2шт.

-

5604-1402

TRACK ASS'Y

SC: D

-2шт.

-

5604-1193

TRACK ASS'Y

SC: D

-2шт.

11

5270-9005A

LOWER ROLLER ASS'Y(D.F)

SERIAL: 1-122

4шт.

11

5270-9005A

LOWER ROLLER ASS'Y(D.F)

SERIAL: 123-200

6шт.

11

5270-9005B

LOWER ROLLER ASS'Y(D.F)

SERIAL: 201

6шт.

11A

5270-6072

ROLLER(D.F)

desc: . RACCORD ADAPTATEUR

1шт.

11B

5114-6030

COLLAR

desc: . COLLIER

2шт.

11C

5112-6008

SHAFT

desc: . ARBRE

1шт.

11D

5110-6055

BUSH

desc: . DOUILLE

1шт.

11E

-

RING;SNAP

desc: . BAGUE ELASTIQUE

2шт.

11F

5180-6069

SEAL;GROUP

desc: . ETANCHEITE

2шт.

11G

S8010451

O-RING G45

desc: . JOINT TORIQUE

2шт.

11H

S5810021

PLUG PT1/4

desc: . RACCORD ADAPTATEUR

1шт.

43

S5102703

WASHER;SPRING M12

SERIAL: 1-122

16шт.

43

S5102703

WASHER;SPRING M12

SERIAL: 123

24шт.

50

S0515253

BOLT M12X1.75X30

SERIAL: 1-92

16шт.

56

S0515463

BOLT M12X1.75X40

SERIAL: 93-122

16шт.

56

S0515463

BOLT M12X1.75X40

SERIAL: 123

24шт.
