Запчасти Doosan Daewoo TRAVEL MOTOR(HOUSING) HYDRAULIC PARTS

F32

728493

VALVE BUSHING ASS'Y

desc: CARTER

1шт.

F33

730036

O-RING

desc: JOINT TORIQUE

2шт.

G38

792739

O-RING

desc: . JOINT TORIQUE

3шт.

G42

754580

O-RING

desc: . JOINT TORIQUE

3шт.

G42

754580

O-RING

desc: . JOINT TORIQUE

3шт.

J10E

729442

SPRING

desc: RESSORT

1шт.

M1Q1

506879

HC CONTROL KIT

desc: COMMANDE

1шт.

M10

9007314-1014

SCREW M10X65

desc: . VIS

4шт.

M11

739672

WASHER

desc: . RONDELLE

4шт.

M12

717199

COVER

desc: . COUVERCLE

1шт.

M14

509940

GASKET

desc: . JOINT

1шт.

M16

9003509-0006

NUT

desc: . ECROU

1шт.

M18

9007712-0611

SET;SCREW

desc: . VIS

1шт.

M20

719377

GUIDE;SPRING

desc: . GUIDE

1шт.

M22

729434

SPRING

desc: . RESSORT

1шт.

M24

728998

PISTON

desc: . PISTON

1шт.

M25

728980

SEAT;SPRING

desc: . SIEGE DE RESSORT

1шт.

M26

736983

PIN

desc: . GOUJON

1шт.

M28

9007314-0604

SCREW M6X16

desc: . VIS

4шт.

M34

9005110-5600

PLUG ASS'Y

desc: . BOUCHON

4шт.

M38

505667

SCREW;BLEED

desc: . VIS

1шт.

M40

9003509-0008

NUT

desc: . ECROU

1шт.

M44

505269

VALVE;SHUTTLE

desc: . VANNE

1шт.

M46

625210

SEAT;CHECK BALL

desc: . SIEGE DE BILLE

1шт.

M47

916007

BALL

desc: . BILLE

1шт.

M48

9005110-5600

PLUG ASS'Y

desc: . BOUCHON

1шт.

M48A

9004201-3700

O-RING

desc: . JOINT TORIQUE

1шт.

M50

504519

PLUG ASS'Y

desc: . BOUCHON

1шт.

M50A

9004201-1200

O-RING

desc: . JOINT TORIQUE

1шт.

M1Q2

506890

SEAL KIT

desc: KIT DE JOINT

1шт.

F33

730036

O-RING

desc: . JOINT TORIQUE

2шт.

G36

364968

O-RING

desc: . JOINT TORIQUE

1шт.

G38

792739

O-RING

desc: . JOINT TORIQUE

3шт.

S10

738674

GUIDE;SPRING

desc: SIEGE DE RESSORT

1шт.

S10T

737270

SPRING

desc: RESSORT

1шт.

S11T

737288

SPRING

desc: RESSORT

1шт.

S20

735910

GUIDE;SPRING

desc: SIEGE DE RESSORT

1шт.

S70

737551

SEAT;SPRING

desc: SIEGE DE RESSORT

1шт.
