Запчасти Doosan Daewoo CRANK SHAFT ENGINE PARTS

101

65.02101-6015

CRANK SHAFT ASS'Y

SERIAL: 950603

1шт.

101

65.02101-6018A

CRANK SHAFT ASS'Y

SERIAL: 950604

1шт.

102

65.02101-0043

SHAFT;CRANK

SERIAL: 950603

1шт.

102

65.02101-0045A

SHAFT;CRANK

SERIAL: 950604

1шт.

103

06.22022-3212

PIN;PARALLEL

desc: . GOUJON

1шт.

104

65.02115-0013

GEAR;CRANK SHAFT

desc: PIGNON DE VILEBREQUIN

1шт.

107

65.02120-0002

RING;OIL THROWER

desc: BAGUE

1шт.

108

65.90501-0006

NUT

desc: ECROU

1шт.

109

65.93020-0015

BUSH;TAPER

desc: COUSSINET

1шт.

110

65.91501-0006

KEY;SLIDING

desc: KEY

1шт.

201

65.02301-5055

FLY WHEEL ASS'Y

desc: ENSEMBLE VOLANT

1шт.

202

65.02310-0006

GEAR;STARTING RING

desc: . ENGRENAGE

1шт.

204

65.02301-0203

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

207

06.01494-4506

BOLT;HEX. M16X1.5X35

desc: BOULON A 6 PANS

6шт.

208

65.90701-0021

WASHER

SERIAL: 970703

1шт.

208

06.16731-2111

WASHER;SPRING

SERIAL: 970704

6шт.

301

65.02401-6002

CONNECTING ROD ASS'Y

SERIAL: 409999

6шт.

301

65.02401-6161

CONNECTING ROD ASS'Y

SERIAL: 500001

6шт.

302

65.02401-0002

ROD;CONNECTING

SERIAL: 409999

1шт.

302

65.02401-0161

ROD;CONNECTING

SERIAL: 500001

1шт.

303

65.02405-0002

BUSH

SERIAL: 409999

1шт.

303

65.02405-1060

BUSH

SERIAL: 500001

1шт.

305

65.02411-0002

BOLT

SERIAL: 409999

2шт.

305

65.02411-0006

BOLT

SERIAL: 500001

2шт.

306

65.02410-6083

METAL;CON ROD STD

SERIAL: 000327

6шт.

306

65.02410-6003A

METAL;CON ROD STD

SERIAL: 000328

6шт.

401

65.02501-0152

PISTON(ALTV)

SERIAL: 960005

6шт.

401

65.02501-0176

PISTON(ALTV)

SERIAL: 970014

6шт.

401

65.02501-0195

PISTON(ALTV)

SERIAL: 970015

6шт.

402

65.02501-0153

GRADE(A GRADE)

SERIAL: 960005

6шт.

402

REP_PNO: 65.02503-0099

-1шт.

402

REP_PNO: 65.02503-0116

-1шт.

402

REP_PNO: 65.02503-0114

-1шт.

402

65.02501-0177

GRADE(A GRADE)

SERIAL: 970014

6шт.

402

REP_PNO: 65.02503-0099

-1шт.

402

REP_PNO: 65.02503-0116

-1шт.

402

REP_PNO: 65.02503-0114

-1шт.

402

65.02501-0196

GRADE(A GRADE)

SERIAL: 970015

6шт.

403

65.02501-0154

GRADE(B GRADE)

SERIAL: 960005

6шт.

403

REP_PNO: 65.02503-0099

-1шт.

403

REP_PNO: 65.02503-0116

-1шт.

403

REP_PNO: 65.02503-0114

-1шт.

403

65.02501-0178

GRADE(B GRADE)

SERIAL: 970014

6шт.

403

REP_PNO: 65.02503-0099

-1шт.

403

REP_PNO: 65.02503-0116

-1шт.

403

REP_PNO: 65.02503-0114

-1шт.

403

65.02501-0197

GRADE(B GRADE)

SERIAL: 970015

6шт.

404

65.02503-0099

RING;TOP

desc: SEGMENT COUP DE FEU

6шт.

405

65.02503-0098

RING;SECOND

SERIAL: 951016

6шт.

405

65.02503-0116

RING;SECOND

SERIAL: 951017

6шт.

406

65.02503-0096

RING;OIL

SERIAL: 960005

6шт.

406

65.02503-0114

RING;OIL

SERIAL: 960006

6шт.

412

65.02502-0002

PIN;PISTON

desc: AXE DE PISTON

6шт.

413

06.29020-0121

RING;RETAINING

desc: RONDELLE DE RETENUE

12шт.

501

65.02601-0094

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

503

65.02122-0001

COVER;DUST

desc: PARE-POUSSIERES

1шт.
