Запчасти Doosan Daewoo WATER PUMP & COOLING FAN ENGINE PARTS

101

65.06500-6013

WATER PUMP ASS'Y

SERIAL: 500002

1шт.

101

65.06500-6395

WATER PUMP ASS'Y

SERIAL: 500003

1шт.

101

65.06500-6400

WATER PUMP ASS'Y

SERIAL: 970628

1шт.

102

65.06501-0068

HOUSING

SC: D

1шт.

103

65.06520-6007

SEAL;MECHANICAL

desc: . JOINT

1шт.

104

65.93410-0027

BEARING

desc: . PALIER

1шт.

105

06.29020-0132

RING;SNAP

desc: . BAGUE ELASTIQUE

1шт.

106

65.06504-0033

HUB;V-BELT PULLEY

desc: . MOYEU

1шт.

107

65.06506-0021

IMPELLER

desc: . TURBINE

1шт.

108

65.06512-0002

COVER

desc: . COUVERCLE

1шт.

109

65.06901-0003

GASKET

desc: . JOINT

1шт.

110

06.04200-9009

SCREW;CROSS M8X20

desc: . VIS

3шт.

111

06.01493-4214

BOLT;HEX. M10X1.25X75

desc: BOULON A 6 PANS

1шт.

112

06.01943-3221

BOLT;HEX. M10X1.25X50

desc: BOULON A 6 PANS

2шт.

113

06.01913-3218

BOLT;HEX. M10X1.25X35

desc: BOULON A 6 PANS

1шт.

114

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

115

65.06503-0050

PULLEY;V-BELT

SERIAL: 500002

1шт.

115

65.06503-0075

PULLEY;V-BELT

SERIAL: 500003

1шт.

116

65.06901B0002

GASKET;WATER PUMP

desc: JOINT

1шт.

201

65.06601-5008

FAN;COOLING(6 BLADE)

SERIAL: 0213

1шт.

202

65.06611-0019

FAN;FLANGE

SERIAL: 500002

1шт.

202

65.06611-0097

FAN;FLANGE

SERIAL: 500003

1шт.

203

06.01013-9124

BOLT;HEX M8X95

desc: BOULON A 6 PANS

4шт.

204

06.16731-2107

WASHER;SPRING A8

desc: RONDELLE ELASTIQUE

4шт.

209

65.96801-0095

V-BELT L=1260

desc: COURROIE

1шт.
