Запчасти Doosan Daewoo FUEL SYSTEM ENGINE PARTS

101

65.10101-7022

NOZZLE HOLDER ASS'Y

SERIAL: 970015

6шт.

101

65.10101-7078

NOZZLE HOLDER ASS'Y

SERIAL: 970016

6шт.

101

65.10101-7295

NOZZLE HOLDER ASS'Y

SERIAL: 800001

6шт.

102

65.10101-6007

HOLDER;NOZZLE

SERIAL: 970015

1шт.

102

65.10101-6021

HOLDER;NOZZLE

SERIAL: 800001

1шт.

103

65.10102-0007

NOZZLE

SERIAL: 970015

1шт.

103

65.10102-6044

NOZZLE

SERIAL: 800001

1шт.

104

65.96507-0004

RING;SEAL

desc: BAGUE D'ETANCHEITE

6шт.

105

65.96507-0011

RING;SEAL

SERIAL: 700999

6шт.

105

65.96507-0046

RING;SEAL

SERIAL: 800001

6шт.

106

06.06125-8711

BOLT;STUD

desc: ECROU 6 PANS

12шт.

107

06.11063-8214

NUT;HEX. M8

desc: ECROU 6 PANS

12шт.

108

06.16731-2107

WASHER;SPRING

desc: RONDELLE

12шт.

201

65.10301-6142

PRESSURE PIPE ASS'Y

SERIAL: 309999

1шт.

201

65.10301-6144

PRESSURE PIPE ASS'Y

SERIAL: 400001

1шт.

301

65.11101-7248

PUMP;INJECTION

SERIAL: 970321

1шт.

301

65.11101-7286

PUMP;INJECTION

SERIAL: 970322

1шт.

301

65.11101-7321

PUMP;INJECTION

SERIAL: 000222

1шт.

301A

65.12101-7004S

FEED PUMP

desc: . POMPE D'INJECTION

1шт.

301B

31151-322S

PLUNGER

desc: . POMPE D'INJECTION

6шт.

301C

65.131160-1120

VALVE;DELIVERY

desc: . POMPE D'INJECTION

1шт.

301D

131424-1520

VALVE;OVERFLOW

desc: . POMPE D'INJECTION

1шт.

301E

156636-5620

COUPLING

desc: . POMPE D'INJECTION

1шт.

308

65.05701-5200

PIPE;OIL

desc: ECROU 6 PANS

1шт.

309

65.98155-0011

UNION;HOLLOW

desc: RONDELLE ELASTIQUE

1шт.

310

06.12172-9314

NUT;CAP

desc: POMPE D'INJECTION

1шт.

311

06.56180-0714

RING;SEAL A10X15

desc: POMPE D'INJECTION

2шт.

401

06.01913-3122

BOLT ASS'Y M8X55

desc: ECROU 6 PANS

7шт.

402

06.01913-3124

BOLT ASS'Y M8X65

desc: RONDELLE ELASTIQUE

1шт.

406

65.11401-0002C

BRACKET;REAR

desc: POMPE D'INJECTION

1шт.

407

06.01953-3213

BOLT ASS'Y M10X1.25X20

desc: FIL

2шт.

408

06.15010-2312

WASHER;PLAIN

desc: FIL

1шт.

409

06.16731-2108

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

410

06.11063-9215

NUT M10X1.25

desc: ECROU 6 PANS

1шт.

411

65.11902A0001

GASKET

desc: RONDELLE ELASTIQUE

1шт.

501

65.12301-5022

PIPE;FUEL(RETURN)

desc: CANALISATION DE GAZOLE

1шт.

502

65.12301-5019

PIPE;FUEL

SERIAL: 960223

1шт.

502

65.12301-5817

PIPE;FUEL

SERIAL: 960224

1шт.

503

65.12301-5018

PIPE;FUEL

SERIAL: 960223

1шт.

503

65.12301-5816

PIPE;FUEL

SERIAL: 960224

1шт.

504

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

505

65.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

506

06.78144-2204

SCREW;HOLLOW

desc: VIS CREUSE

1шт.

507

06.56190-0706

RING;SEAL A14X20

desc: BAGUE D'ETANCHEITE

2шт.

508

65.12301-5021

PIPE;FUEL(RETURN)

SERIAL: 960015

1шт.

508

65.12301-5210

PIPE;FUEL(RETURN)

SERIAL: 960016

1шт.

509

65.98150-0015B

SCREW;HOLLOW

desc: VIS CREUSE

7шт.

510

06.56180-0712

RING;SEAL A8X14

desc: BAGUE D'ETANCHEITE

14шт.

511

65.12301-5020

PIPE;FUEL(RETURN)

SERIAL: 500999

1шт.

511

65.12301-5818

PIPE;FUEL(RETURN)

SERIAL: 600001

1шт.

512

65.11120-5001

OVER FLOW VALVE ASS'Y

desc: CLAPET DE DECHARGE

1шт.

513

65.96507-0010

RING;SEAL

desc: BAGUE D'ETANCHEITE

3шт.

514

06.12172-9316

NUT;CAP M14x1.5

desc: BAGUE D'ETANCHEITE

1шт.

515

65.97401-6009

PIPE CLIP ASS'Y

desc: CONDUITE

1шт.
