Запчасти Doosan Daewoo AIR CLEANER POWER TRAIN

-

K1021934

AIR CLEANER ASS'Y

SC: D

-2шт.

1

204-00030

AIR CLEANER

desc: FILTRE A AIR

1шт.

1A

474-00025

ELEMENT;INNER

desc: . ELEMENT FILTRANT

1шт.

1B

474-00024

ELEMENT;OUTER

desc: . ELEMENT FILTRANT

1шт.

1C

K1019101

VALVE;VACUATOR

desc: . VALVE DE VACUATOR

1шт.

2

K1019099

BRACKET

desc: SUPPORT

1шт.

3

K1021622

HOSE;AIR CLEANER INLET

desc: TUYAUX D'AIR

1шт.

4

S8450066

CLAMP:HOSE

desc: COLLIER

4шт.

5

S0509063

BOLT

desc: BOULON A 6 PANS

5шт.

6

K1019645

INDICATOR;DUST

desc: INDICATEUR

1шт.

7

K1023146

WASHER;HARDENED

desc: RONDELLE

8шт.

8

S4016533

NUT

desc: ECROU

3шт.

9

K1022331

REDUCER

desc: REDUCTEUR

1шт.

10

K1022324

ADAPTER

desc: ADAPTEUR

1шт.

11

K1022322

HOSE

SC: CM

60шт.

12

K1023150

WASHER;HARDENED

desc: RONDELLE

1шт.

13

S8450006

CLAMP:HOSE

desc: COLLIER

2шт.

14

K1020764

PLATE

desc: PLAQUE

1шт.

15

K1021624

TUBE

desc: TUBE

1шт.

16

K1021623

HOSE;AIR CLEANER INLET

desc: TUYAUX D'AIR

1шт.
