Запчасти Doosan Daewoo HIGH FLOW PIPING OPTION PARTS

-

K1023366

HIGH FLOW ASS'Y

SC: D

-2шт.

1

K1019925

VALVE;SOLENOID

desc: SOUPAPE A SOLENOIDE

1шт.

2

K1020934

PLATE

desc: PLAQUE

1шт.

3

K1019924

VALVE;SOLENOID

desc: SOUPAPE A SOLENOIDE

1шт.

4

K1022790

PUMP;GEAR

desc: POMPE A ENGRENAGE

1шт.

5

K1020211

SLEEVE;POWER-BEYOND

desc: MANCHON

1шт.

6

K1019934

VALVE;CHECK

desc: VANNE DE CONTROLE

1шт.

7

K1020935

PLATE

desc: PLAQUE

1шт.

8

K1020961

PROTECTOR;HOSE

desc: PROTECTEUR

1шт.

9

K1019923

BRACKET

desc: SUPPORT

1шт.

10

K1019926

CLAMP;TUBE

desc: COLLIER

2шт.

11

K1020101

CLIP

desc: BAGUE D'ARRET

2шт.

12

DS2011332

HOSE

desc: TUYAU FLEXIBLE

1шт.

13

K1023066

ELBOW

desc: COUDE

2шт.

14

DS2013819

HOSE

desc: TUYAU FLEXIBLE

2шт.

15

DS2012049

HOSE

desc: TUYAU FLEXIBLE

1шт.

16

DS2024007

HOSE

desc: TUYAU FLEXIBLE

2шт.

17

K1020955

HOSE

desc: TUYAU FLEXIBLE

1шт.

18

DS2019005

HOSE

desc: TUYAU FLEXIBLE

1шт.

19

DS2021036

HOSE

desc: TUYAU FLEXIBLE

1шт.

20

DS2022023

HOSE

desc: TUYAU FLEXIBLE

1шт.

21

K1020080

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

22

K1020081

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

23

K1020082

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

24

K1020217

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

25

K1020458

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

26

K1020083

TEE

desc: TE

1шт.

27

K1019076

PIPE

desc: CONDUITE

1шт.

28

K1023057

O-RING

desc: JOINT TORIQUE

1шт.

29

K1023046

FLANGE;HALF

desc: BRIDE

2шт.

30

K1020960

HOSE

desc: TUYAU FLEXIBLE

2шт.

31

K1022470

ELBOW

desc: COUDE

1шт.

32

K1020462

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

33

K1020463

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

34

K1020084

TEE

desc: TE

1шт.

35

K1020103

ADAPTER

desc: RACCORD ADAPTATEUR

2шт.

36

K1020102

ADAPTER

desc: RACCORD ADAPTATEUR

1шт.

37

K1020085

TEE

desc: TE

1шт.

38

S8450035

CLAMP;HOSE

desc: COLLIER

4шт.

39

K1020936

TUBE

desc: TUBE

1шт.

40

K1020937

TUBE

desc: TUBE

1шт.

41

K1020938

TUBE

desc: TUBE

1шт.

42

K1020074

COUPLER

desc: FIXATION DE POMPE

1шт.

43

K1020075

COUPLER

desc: FIXATION DE POMPE

1шт.

44

K1020073

COUPLER

desc: FIXATION DE POMPE

1шт.

45

K1021478

BRACKET

desc: SUPPORT

1шт.

46

S0559763

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

47

S4016633

NUT

desc: ECROU

2шт.

48

K1023147

WASHER;HARDENED

desc: RONDELLE

4шт.

49

S0556663

BOLT

desc: BOULON A 6 PANS

2шт.

50

S0508863

BOLT

desc: BOULON A 6 PANS

4шт.

51

K1020209

BLOCK

desc: BLOC

2шт.

52

K1020076

TEE

desc: TE

1шт.

53

K1022934

HOUSING;RECEPTACLE

desc: BOITIER

1шт.

54

S8450023

CLAMP;HOSE

desc: COLLIER

3шт.

55

DS2012147

HOSE

desc: TUYAU FLEXIBLE

1шт.

56

K1020088

PIN;WEDGE LOCK

desc: GOUJON

1шт.

57

K1022963

HOUSING;PIN

desc: BOITIER

1шт.

58

S0512363

BOLT

desc: BOULON A 6 PANS

1шт.

59

S0553663

BOLT

desc: BOULON A 6 PANS

2шт.

60

S4012343

NUT

desc: ECROU

2шт.

61

K1023148

WASHER;HARDENED

desc: RONDELLE

2шт.

62

K1020532

HARNESS;HIGH FLOW

desc: FAISCEAU

2шт.

63

K1021941

HANDLE

desc: POIGNEE

1шт.

64

K1022550

PROTECTOR;HOSE

desc: PROTECTEUR

178шт.

65

K1022971

CLIP;BAND

desc: ATTACHE

6шт.

66

S8040161

O-RING

desc: JOINT TORIQUE

2шт.

67

S8040121

O-RING

desc: JOINT TORIQUE

6шт.

68

S8040101

O-RING

desc: JOINT TORIQUE

2шт.

69

S8040081

O-RING

desc: JOINT TORIQUE

2шт.

70

S8030121

O-RING

desc: JOINT TORIQUE

13шт.

71

S8030101

O-RING

desc: JOINT TORIQUE

9шт.

72

S8030081

O-RING

desc: JOINT TORIQUE

4шт.

73

K1019698

RELAY;SEALED

desc: RELAIS

2шт.

74

K1022543

HOSE;BULK

desc: TUYAU FLEXIBLE

116шт.

75

K1023047

BOLT

desc: BOULON A 6 PANS

4шт.

76

K1023094

HOSE;BULK

desc: TUYAU FLEXIBLE

145шт.

77

K1020787

TEE;BULK

desc: TE

1шт.
