Запчасти Doosan Daewoo ENGINE MOUNTING BODY PARTS

-

201-00189A

ENGINE ASS'Y

SC: D

-2шт.

6

195-02626B

BRACKET;ENGINE MOUNT

desc: SUPPORT

1шт.

7

195-02625B

BRACKET;ENGINE MOUNT

SERIAL: 5001-5219

1шт.

7

195-02625C

BRACKET;ENGINE MOUNT

SERIAL: 5220

1шт.

8

161-00551

RUBBER;MOUNT ENGINE

desc: CAOUTCHOUC

4шт.

9

161-00553

RUBBER;MOUNT ENGINE

desc: CAOUTCHOUC

4шт.

19

2114-1929

WASHER

desc: RONDELLE

4шт.

20

195-02643C

SUPPORT;NUT

desc: SUPPORT

4шт.

21

2114-9012A

WASHER;HARDEN

desc: RONDELLE

8шт.

25

S0771466

BOLT M20X1.5X130

desc: BOULON A 6 PANS

4шт.

26

S0521466

BOLT M16X2.0X40

desc: BOULON A 6 PANS

8шт.

27

S5102903

WASHER;SPRING M16

desc: RONDELLE ELASTIQUE

8шт.

70

K1008284

ENGINE ASS'Y-TIER-III

desc: MOTEUR

1шт.
