Запчасти Doosan Daewoo ELECTRIC BOX ASSY BODY PARTS

-

500-00284B

ELECTRIC BOX ASS'Y

SERIAL: 5001-5379

1шт.

-

500-00284C

ELECTRIC BOX ASS'Y

SERIAL: 5380

1шт.

1

621-02955B

PLATE;ELECTRIC BOX

desc: PLAQUE

1шт.

2

543-00108

CONTROLLER;E-EPOS

SERIAL: 5001-5379

1шт.

2

543-00108A

CONTROLLER;E-EPOS

SERIAL: 5380

1шт.

3

S5010613

WASHER;PLAIN M10

desc: RONDELLE PLATE

4шт.

4

S5102603

WASHER;SPRING M10

desc: RONDELLE ELASTIQUE

4шт.

5

S4012633

NUT M10x1.5

desc: ECROU

4шт.

6

2543-9015

CONTROLLER;STARTER

desc: COMMANDE

1шт.

7

543-00106

CONTROLLER;WIPER

desc: COMMANDE

1шт.

8

2531-1003

CONVERTER;DC-DC

desc: CONVERTEUR

1шт.

9

2531-1003

CONVERTER;DC-DC

desc: CONVERTEUR

1шт.

10

S3450953

SCREW M6X1.0X12

desc: VIS

8шт.

11

S5102303

WASHER;SPRING M6

desc: RONDELLE ELASTIQUE

8шт.

12

545-00011

RESISTOR;AUXILIARY

desc: RESISTOR;AUXILIARY

1шт.

13

S3450863

SCREW M5X0.8X22

desc: VIS

2шт.

14

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

2шт.

15

2544-9033

RELAY

desc: RELAIS

1шт.

16

2544-9033

RELAY

desc: RELAIS

1шт.

17

2544-9033

RELAY

desc: RELAIS

1шт.

18

2544-9033

RELAY

desc: RELAIS

1шт.

19

2544-9033

RELAY

desc: RELAIS

1шт.

20

2544-9033

RELAY

desc: RELAIS

1шт.

21

2544-9033

RELAY

desc: RELAIS

1шт.

22

2544-9033

RELAY

desc: RELAIS

1шт.

23

2544-9033

RELAY

desc: RELAIS

1шт.

24

S3450833

BOLT M5X0.8X12

desc: BOULON A 6 PANS

4шт.

25

S5100203

WASHER;SPRING M5

desc: RONDELLE ELASTIQUE

4шт.

26

190-01192D9

PLATE;NAME(RELAY)

desc: PLAQUE D'IDENTIFICATION

1шт.

27

190-01192D2

PLATE;NAME(RELAY)

desc: PLAQUE D'IDENTIFICATION

1шт.

28

530-00412G

HARNESS;ELECTRIC BOX

desc: FAISCEAU

1шт.

29

124-00208D3

CLIP

desc: ATTACHE

2шт.

30

124-00208D2

CLIP

desc: ATTACHE

1шт.

31

K1001029

BOLT

desc: BOULON A 6 PANS

3шт.

32

2544-9033

RELAY

desc: RELAIS

1шт.
