Запчасти Doosan Daewoo TRACK SPRING TRACK PARTS

-

604-00239A

TRACK ASS'Y

SC: D

-2шт.

6

440-00426B

ADJUSTER ASS'Y;TRACK

SERIAL: 5001-5377

2шт.

6

440-00426C

ADJUSTER ASS'Y;TRACK

SERIAL: 5378

2шт.

6-1

274-00009A

TRACK SPRING ASS'Y

SERIAL: 5001-5186

1шт.

6-1

274-00009B

TRACK SPRING ASS'Y

SERIAL: 5187-5377

1шт.

6-1

274-00009C

TRACK SPRING ASS'Y

SERIAL: 5378

1шт.

6-1A

440-00427A

CYLINDER BODY

SERIAL: 5011-5377

1шт.

6-1A

440-00427B

CYLINDER BODY

SERIAL: 5378

1шт.

6-1B

444-00009A

PISTON ROD

SERIAL: 5001-5186

1шт.

6-1B

444-00009B

PISTON ROD

SERIAL: 5187

1шт.

6-1C

195-02644

BRACKET

desc: .. SUPPORT

1шт.

6-1D

114-00565A

SPACER

desc: .. ENTERTOISE

1шт.

6-1E

215-00038A

SHAFT

desc: .. ARBRE

1шт.

6-1F

129-00151

SPRING

desc: .. RESSORT

1шт.

6-1G

121-00083

NUT;LOCK

desc: .. VERROU

1шт.

6-1H

621-02717

PLATE;LOCK

desc: .. PLAQUE

1шт.

6-1I

S0515363

BOLT

desc: .. BOULON A 6 PANS

2шт.

6-1J

S5741270

PIN;SPRING

desc: .. GOUJON

1шт.

6-1K

S5102703

WASHER;SPRING

desc: .. RONDELLE ELASTIQUE

2шт.

6-1L

180-00459

PACKING

SC: K

1шт.

6-1M

180-00460

RING;BACK UP

SC: K

1шт.

6-1N

180-00461

SEAL;DUST

SC: K

1шт.

6-1P

K1002407

CYLINDER ASS'Y

desc: .. CYLINDRE

1шт.

6-3

S0565466

BOLT

desc: . BOULON A 6 PANS

4шт.

6-4

S5102903

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

4шт.

30

422-00055

VALVE;GREASE

desc: VANNE

2шт.

*

274-00009KT

SEAL KIT;TRACK SPRING

desc: KIT DE JOINT

1шт.
