Запчасти Doosan Daewoo BUCKET CYLINDER - ARM 2.5M HYDRAULIC PARTS

-

K1007679

BUCKET CYLINDER

desc: VERIN DE GODET

1шт.

1

K9001285

TUBE ASS'Y

desc: DOUILLE ACIER

1шт.

2

110-00251

BUSH

desc: BAGUE

1шт.

3

K9001151

ROD ASS'Y

desc: TIGE

1шт.

4

110-00253

BUSH

desc: BAGUE

1шт.

5

1.442-00005

COVER;ROD

desc: COUVERCLE

1шт.

6

110-00080

DD-BUSH

desc: COUSSINET

1шт.

7

115-00063

RING;RETAINING

desc: BAGUE

1шт.

8

1.180-00657

SEAL;BUFFER

SC: K

1шт.

9

K9001153

U-PACKING

SC: K

1шт.

10

K9001154

RING;BACK UP

SC: K

1шт.

11

115-00072

WIPER;DUST

SC: K

1шт.

12

115-00073

RING;RETAINING

desc: BAGUE

1шт.

13

S8011351

O-RING

SC: K

1шт.

14

1.180-00662

RING;BACK UP

SC: K

1шт.

15

2180-1217D96

O-RING

SC: K

1шт.

16

1.411-00003

RING;CUSHION

desc: BAGUE D'AMORTISSEMENT

1шт.

17

K9001155

PISTON

desc: PISTON

1шт.

18

K9001148

SEAL;SLIPPER

SC: K

1шт.

19

115-00079

RING;WEAR

SC: K

2шт.

20

K9001149

RING;SLYD

SC: K

2шт.

21

S8010701

O-RING

SC: K

1шт.

22

K9001156

RING;BACK UP

SC: K

2шт.

23

121-00045

NUT;PISTON

desc: ECROU

1шт.

24

1.120-00219

SCREW;SET

desc: VIS

1шт.

25

S2222272

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

14шт.

26

1.124-00060

PIPE BAND ASS'Y-H

desc: ENSEMBLE DE FIXATION

1шт.

27

124-00052

BAND;PIPE

desc: ATTACHE

1шт.

28

S5100703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

29

S0560453

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

30

K9001157

PIPE BAND ASS'Y-R

desc: ENSEMBLE DE FIXATION

1шт.

31

124-00052

BAND;PIPE

desc: ATTACHE

1шт.

32

S5100703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

33

S0560453

BOLT;HEX

desc: BOULON A 6 PANS

2шт.

34

K9001286

PIPE ASS'Y-H

desc: ENSEMBLE CONDUITES

1шт.

35

S8000341

O-RING

desc: JOINT TORIQUE

1шт.

36

S5100703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

37

S2215961

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

4шт.

38

K9001287

PIPE ASS'Y-R

desc: ENSEMBLE CONDUITES

1шт.

39

S8000341

O-RING

desc: JOINT TORIQUE

1шт.

40

S5100703

WASHER;SPRING

desc: RONDELLE ELASTIQUE

4шт.

41

S2215961

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

4шт.

42

K9001158

BOLT;U

desc: BOULON A 6 PANS

1шт.

43

S5100603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

2шт.

44

S4012633

NUT;HEX

desc: ECROU

2шт.

45

K9001159

CLAMP;PIPE

desc: FIXATION DE TUYAU

1шт.

46

S5102903

WASHER;SPRING

desc: RONDELLE ELASTIQUE

1шт.

47

S0565451

BOLT

desc: BOULON A 6 PANS

1шт.

48

S6710032

NIPPLE;GREASE PT1/8

desc: GRAISSEUR

2шт.

*

K9001009

SEAL KIT;BUCKET CYL

desc: KIT DE JOINT

1шт.
