Запчасти Doosan Daewoo TRAVEL REDUCTION GEAR HYDRAULIC PARTS

-

K1013467

MOTOR;TRAVEL

desc: MOTEUR

2шт.

1

K9005304

REDUCTION GEAR

desc: VITESSE DE REDUCTION

1шт.

1-1

-

HOLDER;FLANGE

SC: D

1шт.

1-2

K9003721

SEAL;FLOATING

desc: JOINT

2шт.

1-3

K9005287

BEARING;ANGULAR

desc: ROULEMENT

1шт.

1-4

K9003723

NUT;RING

desc: ECROU

1шт.

1-5

K9005285

PLUG

desc: BOUCHON

2шт.

1-6

-

HOUSING

SC: D

1шт.

1-7

S6250110

BALL;STEEL

desc: BOULE

132шт.

1-8

2181-1116D1

PLUG

desc: BOUCHON

2шт.

1-9

K9005308

GEAR;PLANETARY

desc: PIGNON

4шт.

1-10

K9005294

BEARING;NEEDLE

desc: ROULEMENT

4шт.

1-11

K9005296

RACE;INNER

desc: RACE INTERIEUR

4шт.

1-12

K9005310

PLATE;THRUST

desc: PLAQUE

4шт.

1-13

K9005286

WASHER;THRUST

desc: RONDELLE DE BUTEE

1шт.

1-14

K9003730

SCREW

desc: VIS

4шт.

1-15

K9005307

GEAR;SUN

desc: PIGNON

1шт.

1-16

S6500350

RING;SNAP

desc: BAGUE D'ARRET

1шт.

1-17

K9005305

HOLDER

desc: SUPPORT

1шт.

1-18

K9005309

GEAR;PLANETARY

desc: PIGNON

3шт.

1-19

K9005295

BEARING;NEEDLE

desc: ROULEMENT

3шт.

1-20

K9005297

RACE;INNER

desc: RACE INTERIEUR

3шт.

1-22

K9005306

GEAR;DRIVE

desc: PIGNON

1шт.

1-23

-

PLATE;THRUST

SC: D

1шт.

1-24

K9005311

COVER

desc: COUVERCLE

1шт.

1-25

S8011551

O-RING

desc: JOINT TORIQUE

1шт.

1-26

K9003739

WIRE

desc: FIL

1шт.

1-27

K9003803

PLUG

desc: BOUCHON

2шт.

1-28

S8000111

O-RING

desc: JOINT TORIQUE

3шт.
