Запчасти Doosan Daewoo BUCKET - 0.08M©ш FRONT PARTS

1

K1015892C

BUCKET ASS'Y - 0.08m3

desc: ENSEMBLE GODET

1шт.

1-1

K1015914C

BUCKET

desc: . GODET

1шт.

1-2

2713-1212B

TOOTH

desc: . CHEVILLE DE DENT

4шт.

1-3

2120-2124

BOLT

desc: . BOULON

8шт.

1-4

2121-1301

NUT

desc: . ECROU

8шт.

1-5

S5102901

WASHER;SPRING

desc: . RONDELLE ELASTIQUE

8шт.

1-6

2713-1206B

CUTTER;SIDE(L.H)

desc: . COIN DE GODET DROIT

1шт.

1-7

2713-1207B

CUTTER;SIDE(R.H)

desc: . COIN DE GODET DROIT

1шт.

1-8

S0515253

BOLT

desc: . BOULON

6шт.

1-9

S5102703

WASHER;SPRING(M12)

desc: . RONDELLE ELASTIQUE

6шт.

1-10

S4012733

NUT

desc: . ECROU

6шт.

12

S8000651

O-RING

desc: JOINT TORIQUE

4шт.
