Запчасти Doosan Daewoo GENERATOR ENGINE PARTS

1

K9004665

ADJUSTER;BELT

desc: AJUSTEZ

1шт.

2

K9004778

GENERATOR

desc: GENERATEUR

1шт.

3

K9004871

NUT

desc: . ECROU

1шт.

4

K9004607

ROTOR ASS'Y

desc: . GROUPE ROTATIF

1шт.

5

K9004618

BEARING;BALL

desc: .. ROULEMENT

1шт.

6

K9004619

COVER;BEARING

desc: .. COUVERCLE

1шт.

7

K9004630

WASHER;THRUST

desc: . RONDELLE DE BUTEE

1шт.

8

K9004608

FLAME DRIVE ASS'Y

desc: . COMMANDE DE FLAMME

1шт.

9

K9004614

BEARING;BALL

desc: .. ROULEMENT

1шт.

10

K9004615

PLATE

desc: .. PLAQUE

1шт.

11

K9004616

SCREW

desc: .. VIS

4шт.

12

K9004617

BOLT;STUD

desc: .. BOULON DE GOUJON

2шт.

13

K9004609

FLAME REAR ASS'Y

desc: . ARRIERE DE FLAMME

1шт.

14

K9004779

COVER

desc: . COUVERCLE

1шт.

15

K9004610

PULLEY

desc: . POULIE

1шт.

16

K9004611

NUT

desc: . ECROU

1шт.

17

K9004780

REGULATOR ASS'Y

desc: . REGULATEUR

1шт.

18

K9004620

HOLDER

desc: . SUPPORT

1шт.

19

K9004621

HOLDER;BRUSH

desc: . SUPPORT

1шт.

20

K9004612

BRUSH ASS'Y

desc: .. BROSSE

2шт.

21

K9004622

SPRING

desc: .. RESSORT

2шт.

22

K9004623

SCREW

desc: . VIS

1шт.

23

K9004624

SCREW

desc: . VIS

1шт.

24

K9004625

BOLT

desc: . BOULON

3шт.

25

K9004626

SCREW;W/WASHER

desc: . VIS

2шт.

26

K9004627

BOLT

desc: . BOULON

2шт.

27

K9004628

INSULATION;BUSH

desc: . ISOLATION

1шт.

28

K9004629

NUT

desc: . ECROU

2шт.

29

K9004613

COLLAR

desc: . COLLIER

1шт.

30

K9004795

STUD

desc: BOULON

1шт.

31

2.121-00268

NUT

desc: ECROU

1шт.

32

2.120-00044

BOLT M8X45

desc: BOULON

1шт.

33

K9004668

ADJUSTER;BELT

desc: AJUSTEZ

1шт.

34

K9004803

BOLT;ADJUSTING

desc: BOULON

1шт.

35

537-00071

TIMER

desc: TEMPORISATEUR

1шт.
