Запчасти Doosan Daewoo CYLINDER HEAD & COVER ENGINE PARTS

1

2.197-00046

LIFTER;ENGINE

desc: POUSSOIR DE MOTEUR

2шт.

2

2.120-00136

BOLT M8X16

desc: BOULON

4шт.

3

K9005154

ROCKER ARM SHAFT ASS'Y

desc: BRAS DE CULBUTEUR

1шт.

4

K9005155

SHAFT;ROCKER ARM

desc: . ARBRE

1шт.

6

K9004637

SUPPORT;ROCKER ARM

desc: . SUPPORT

2шт.

7

K9004638

SUPPORT;ROCKER ARM

desc: . SUPPORT

2шт.

8

K9004639

STUD

desc: . BOULON

3шт.

9

K9004742

SPRING

desc: . RESSORT

3шт.

10

K9005159

ROCKER ARM ASS'Y

desc: . BRAS DE CULBUTEUR

6шт.

11

2.120-00694

SCREW;VALVE

desc: .. VIS

6шт.

13

2.121-00084

NUT

desc: .. ECROU

6шт.

14

K9005147

CAP;VALVE

desc: CHAPEAU

6шт.

15

K9005160

CYLINDER HEAD ASS'Y

desc: CULLASSE

1шт.

19

K9005208

GUIDE;VALVE

desc: . GUIDE

3шт.

21

K9005161

GUIDE;VALVE

desc: . GUIDE

3шт.

23

2.181-00308

PLUG

desc: . BOUCHON

2шт.

24

K9005152

VALVE;INTAKE

desc: . SOUPAPE D'ADMISSION

3шт.

25

K9005153

VALVE;EXHAUST

desc: . VANNE

3шт.

26

K9005188

SPRING;VALVE

desc: . RESSORT

6шт.

27

K9005146

RETAINER;SPRING

desc: . ARRETOIR

6шт.

28

2.180-01240

SEAL;VALVE STEM (INTAKE)

desc: . JOINT

3шт.

29

2.180-01241

SEAL;VALVE STEM (EXHAUST)

desc: . JOINT

3шт.

30

2.217-00072

COTTER

desc: . CLAVETTE

6шт.

32

2.427-00018

SEAT;NOZZLE

desc: SIEGE

3шт.

33

K9005162

RETAINER;NOZZLE

desc: ARRETOIR

3шт.

34

K9004670

WASHER

desc: RONDELLE

3шт.

35

S5740860

PIN;SPRING

desc: GOUPILLE

2шт.

36

K9004854

BOLT M8X25

desc: BOULON

2шт.

37

2.120-00044

BOLT M8X45

desc: BOULON

3шт.

38

K9004855

BOLT M8X50

desc: BOULON

6шт.

39

D460483

CAP;FILLER

desc: CHAPEAU

1шт.

40

K9005158

CYL.HEAD COVER ASS'Y

desc: CULASSE

1шт.

41

K9005150

PLATE;BAFFLE

desc: . PLAQUE

1шт.

42

K9004741

BAFFLE;BREATHER

desc: . CLOISON DE RENIFLARD

1шт.

43

K9004633

PLATE;DIAPHRAGM

desc: . PLAQUE

1шт.

44

K9004634

COVER;DIAPHRAGM

desc: . COUVERCLE

1шт.

45

K9004635

DIAPHRAGM

desc: . DIAPHRAGME

1шт.

46

K9004636

SPRING;DIAPHRAGM

desc: . RESSORT

1шт.

49

K9005156

GASKET;COVER

desc: . JOINT

1шт.

50

2.120-00496

SCREW

desc: . VIS

4шт.

51

2.120-00496

SCREW

desc: . VIS

4шт.

52

2.132-00005

KNOB

desc: BOUTON

3шт.

53

S8000120

O-RING

desc: JOINT TORIQUE

3шт.

54

S8000320

O-RING

desc: JOINT TORIQUE

1шт.

55

2.158-00004

PROTECTOR;NOZZLE

desc: PROTECTEUR

3шт.

56

K9004868

GASKET;LIQUID

desc: JOINT

1шт.
