Запчасти Doosan Daewoo PEDAL VALVE PILOT PIPING (1)

-

K1011188

VALVE;PEDAL

desc: VANNE

1шт.

101

-

CASING

SC: D

1шт.

102

-

CASING

SC: D

1шт.

201

K9003856

COVER

desc: COUVERCLE

2шт.

202

K9003857

PLUG

desc: BOUCHON

4шт.

203

K9003858

CAP;GREASE

desc: CHAPEAU

4шт.

210

K9003859

PACKING

desc: EMBALLAGE

4шт.

211

2180-1216D20

O-RING

desc: JOINT TORIQUE

4шт.

212

2180-1216D25

O-RING

desc: JOINT TORIQUE

4шт.

213

S8000081

O-RING

desc: JOINT TORIQUE

2шт.

214

K9003860

ROD;PUSH

desc: TIGE

4шт.

217

K9003861

SHIM

desc: CALE

4шт.

218

K9003862

SEAT;SPRING

desc: SIEGE

4шт.

224

K9003863

PISTON

SC: D

4шт.

225

S6250092

BALL;STEEL

desc: BOULE

12шт.

251

2181-1890D2

PLUG

desc: BOUCHON

3шт.

252

2.181-00214

PLUG

desc: BOUCHON

2шт.

261

S8000111

O-RING

desc: JOINT TORIQUE

3шт.

271

K9003864

BOLT;SOCKET

desc: BOULON A 6 PANS CREUX

4шт.

301

K9003865

SPOOL

SC: D

4шт.

311

K9003866

SEAT;SPRING

desc: SIEGE

4шт.

313

K9003867

WASHER

desc: RONDELLE

4шт.

324

K9003868

SPRING

desc: RESSORT

4шт.

335

K9003869

SPRING

desc: RESSORT

4шт.

336

K9003870

SPRING

desc: RESSORT

4шт.

413

K9003871

CAM;SHAFT

desc: CAME

2шт.

414

K9003872

BUSH

desc: DOUILLE

4шт.

420

K9003873

CAM

desc: CAME

2шт.

471

S6250161

BALL;STEEL

desc: BOULE

4шт.

472

K9003874

SET SCREW

desc: VIS

2шт.

501

K9003875

BELLOWS

desc: SOUFFLET

2шт.

601

K9003876

CAM ASS'Y

desc: CAME

1шт.
