Запчасти Doosan Daewoo DRIVING SYSTEM ENGINE PARTS

1

65.02101-0069A

CRANK SHAFT

desc: VILEBREQUIN

1шт.

2

06.22022-1018

DOWEL PIN 8M6X45

desc: GOUJON

1шт.

3

65.02115-0016

GEAR;CRANKSHAFT

desc: PIGNON

1шт.

4

65.01110-6140

METAL;MAIN

desc: PALIER

7шт.

5

65.01150-6008

WASHER;THRUST

desc: RONDELLE DE BUTEE

2шт.

10

65.02201-0002

DAMPER;VIBRATION

desc: AMORTISSEUR DE VIBRATIONS

1шт.

11

65.90020-0062B

BOLT;HEX M10X20

desc: BOULON A 6 PANS

6шт.

15

65.02301-5148A

FLYWHEEL ASS'Y

desc: VOLANT

1шт.

16

65.02301-0291A

FLYWHEEL

desc: . ENSEMBLE VOLANT

1шт.

17

65.02310-0006

GEAR;RING

desc: . ENGRENAGE

1шт.

18

65.02130-0004

BUSH;DRIVING

desc: BUISSON

1шт.

19

65.90020-0123

BOLT;COLLARED HEX

desc: BOULON A 6 PANS

8шт.

20

65.02401-6032B

CONNECTING ROD ASS'Y

desc: BIELLE ASS'Y

6шт.

21

65.02411-0009

BOLT;CONNECTING ROD

desc: . VIS DE BIELLE

2шт.

22

65.02410-0040

METAL;CON-ROD(STD)

desc: PALIER

6шт.

22

65.02410-0041

METAL;CON-ROD(0.25)

SC: US

6шт.

22

65.02410-0042

METAL;CON-ROD(0.50)

SC: US

6шт.

23

65.02410-0050

METAL;CON-ROD(STD)

desc: PALIER

6шт.

23

65.02410-0051

METAL;CON-ROD(0.25)

SC: US

6шт.

23

65.02410-0052

METAL;CON-ROD(0.50)

SC: US

6шт.

30

65.02501-0476

PISTON

SC: D

6шт.

31

65.02501-0477

PISTON;A GRADE

desc: . PISTON

6шт.

32

65.02501-0478

PISTON;B GRADE

desc: . PISTON

6шт.

33

65.02503-0132A

RING;PISTON

desc: BAGUE D'ETANCHEITE

6шт.

34

65.02503-0133A

RING;PISTON

desc: BAGUE D'ETANCHEITE

6шт.

35

65.02503-0134

RING;PISTON

desc: BAGUE D'ETANCHEITE

6шт.

36

65.02502-0017A

PIN;PISTON

desc: AXE DE PISTON

6шт.

37

06.29020-0125

RING;LOCK

desc: BAGUE

12шт.

40

65.02601-0225B

PULLEY;V-BELT

desc: POULIE DE COURROIE TRAPEZOIDALE

1шт.

41

65.90701-0099

WASHER

desc: CALE

1шт.

42

06.02106-0723

BOLT;SOCKET

desc: BOULON

8шт.
