Запчасти Doosan Daewoo TWO WAY PIPING - WITH FILTER OPTIONAL PARTS

-

K1009832A

TWO WAY PIPING-WITH FILTER

SC: D

-2шт.

1

DS2011474

HOSE

desc: TUYAU FLEXIBLE

1шт.

2

DS2013667

HOSE

desc: TUYAU FLEXIBLE

1шт.

3

471-00114

FILTER;BREAKER

desc: FILTRE

1шт.

3A

474-00046

ELEMENT;BREAKER FILTER

desc: . ELEMENT

1шт.

4

K1010495A

BRACKET

desc: SUPPORT

1шт.

5

DS0025021

BOLT;SET

desc: BOULON A 6 PANS

4шт.

7

2181-2815D1

ELBOW

desc: COUDE

2шт.

8

S8030161

O-RING

desc: JOINT TORIQUE

2шт.

9

DS0025018

BOLT;SET

desc: BOULON A 6 PANS

4шт.

10

S8000291

O-RING

desc: JOINT TORIQUE

2шт.
