Запчасти Doosan Daewoo CONTROL VALVE - ARTI HYDRAULIC PARTS

-

K1029277

CONTROL VALVE-ARTI

desc: VANNE DE COMMAND

1шт.

1

K9005360

OUTLET SECTION ASS'Y

desc: SECTION DE SORTIE

1шт.

1-2

K9005357

O-RING

desc: . JOINT TORIQUE

1шт.

1-3

2.180-00495

O-RING

desc: . JOINT TORIQUE

2шт.

2

K9005361

OUTLET SECTION ASS'Y

desc: SECTION DE SORTIE

1шт.

2-2

181-00563

PLUG ASS'Y

desc: BOUCHON

1шт.

3

K9005362

SPOOL SECTION ASS'Y

desc: BOBINE

1шт.

3-8

S8010451

O-RING

desc: . JOINT TORIQUE

3шт.

3-9

2.180-00495

O-RING

desc: . JOINT TORIQUE

3шт.

3-10

181-00631

FLANGE

desc: . BRIDE

1шт.

3-11

K9005357

O-RING

desc: . JOINT TORIQUE

1шт.

3-12

K9005358

POPPET

desc: . POUPEE

1шт.

3-13

K9005359

SPRING

desc: . RESSORT

1шт.

3-14

S2212261

BOLT;SOCKET

desc: . BOULON A 6 PANS CREUX

2шт.

3-15

S2212466

BOLT;SOCKET

desc: . BOULON A 6 PANS CREUX

4шт.

4

2.181-00319

PLUG ASS'Y

desc: BOUCHON

1шт.

5

K9005363

VALVE;OVER LOAD

desc: VANNE

2шт.

6

K9005364

ROD;TIE

desc: TIGE

4шт.

7

S4030933

NUT

desc: ECROU

8шт.
