Запчасти Doosan Daewoo AIR CLEANER BODY PARTS

-

K1014064

AIR CLEANER ASS'Y

SC: D

-2шт.

1

204-00067

AIR CLEANER

desc: ENSEMBLE FILTRE A AIR

1шт.

1A

474-00039

ELEMENT;INNER(AIR CLEANER)

desc: . ELEMENT FILTRANT

1шт.

1B

474-00040

ELEMENT;OUTER(AIR CLEANER)

desc: . ELEMENT FILTRANT

1шт.

1C

204-00075

COVER

desc: . COUVERCLE

1шт.

1D

204-00070

VALVE

desc: . VANNE

1шт.

2

124-00298A

BAND;AIR CLEANER

desc: ATTACHE DE TUYAU

2шт.

3

DS0025015

BOLT;SET

desc: BOULON

4шт.

4

193-00913A

PIPE;AIR

desc: TUYAU

1шт.

5

K1014253

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

6

S8510118

CLAMP;HOSE

desc: COLLIER

3шт.

7

K1014328

HOSE;AIR

desc: TUYAU FLEXIBLE

1шт.

8

170-00004

INDICATOR

desc: INDICATEUR

1шт.

9

S5010613

WASHER;PLAIN

desc: RONDELLE PLATE

4шт.

10

S0512066

BOLT

desc: BOULON

4шт.

11

S8510143

CLAMP;HOSE

desc: COLLIER

1шт.

12

K1003618

CAP;DRAIN

desc: BOUCHON

1шт.
