Запчасти Doosan Daewoo CYLINDER BLOCK ENGINE PARTS

1
22
2
12
24
23
20
21
10
30
11
31
34
17
13
14
12
26
15
29
28
16
8
6
7
25
9
5
4
3

Артикул

Название

Примечание

Количество

1

65.01101-6085B

CYLINDER BLOCK ASS'Y

desc: BLOC CYLINDRE

1шт.

2

65.01101-0054B

CYLINDER BLOCK

SC: D

1шт.

3

65.01105-6005B

BEARING CAP ASS'Y(No:3)

SC: D

1шт.

4

65.01105-1051B

CAP;BEARING

SC: D

1шт.

5

65.91710-0001

RING. STOPPER. BRG CAP

desc: .. BAGUE D'ETANCHEITE

2шт.

6

65.01105-6006B

BEARING CAP ASS'Y

SC: D

6шт.

7

65.01105-1052B

CAP;BEARING

SC: D

1шт.

8

65.91710-0001

RING. STOPPER. BRG CAP

desc: .. BAGUE D'ETANCHEITE

2шт.

9

65.90020-0066A

BOLT;BRG CAP

desc: . BOULON A 6 PANS

14шт.

10

65.04410-0021A

BUSH;CAMSHAFT

SC: B

6шт.

11

65.04410-0022

BUSH;CAMSHAFT

SC: B

1шт.

12

65.90302-0009

PLUG;CORE

desc: . BOUCHON B28D

2шт.

13

65.90302-0042

PLUG CORE

desc: . BOUCHON DE DESSABLAGE

8шт.

14

65.90302-0034

PLUG CORE

desc: . BOUCHON DE DESSABLAGE

5шт.

15

65.90302-0041

PLUG CORE

desc: . BOUCHON DE DESSABLAGE

1шт.

16

65.91606-0041

PLUG CORE

desc: . NOYAU DE PRISE

2шт.

17

06.31641-0618

BALL;STEEL

desc: . BILLE

1шт.

20

65.01601-5019

NOZZLE;OIL SPRAY

SERIAL: 060830

6шт.

20

65.01601-5020

NOZZLE;OIL SPRAY

SERIAL: 060331

6шт.

21

65.05401-5031

RELIEF VALVE ASS'Y

desc: SOULAGEMENT VANNE

6шт.

22

65.90320-0022

PLUG SCREW PT1/8

desc: VIS DE REGLAGE

7шт.

23

65.05401-5002F

RELIEF VALVE ASSY

desc: SOULAGEMENT VANNE

1шт.

24

06.56021-0102

O-RING

desc: JOINT TORIQUE

1шт.

25

65.91605-0002

COVER;CORE HOLE

desc: COUVERCLE

1шт.

26

65.90310-0134

SCREW;PLUG

desc: VIS

1шт.

28

65.90310-0135

SCREW;PLUG

desc: BOUCHON A VIS

1шт.

29

06.56190-0705

RING;SEAL

desc: ENSEMBLE BAGUE D'ETANCHEITE

1шт.

30

65.01201-0075A

CYLINDER LINER - GRADE

SC: D

6шт.

31

65.01201-0076

LINER;CYLINDER - 1A

desc: . CHEMISE DE CYLINDRE

6шт.

32

65.01201-0077

LINER;CYLINDER - 1B

desc: . CHEMISE DE CYLINDRE

6шт.

33

65.01201-0078

LINER;CYLINDER - 2A

desc: . CHEMISE DE CYLINDRE

6шт.

34

65.01201-0079

LINER;CYLINDER - 2B

desc: . CHEMISE DE CYLINDRE

6шт.

Выбрано товаров: 32
