Запчасти Doosan Daewoo SUPPORT BODY PARTS

-

195-03329J

SUPPORT & BAFFLE ASS'Y

SC: D

-2шт.

1

195-02742H

SUPPORT ASS'Y

desc: ENSEMBLE DE SUPPORTS

1шт.

1-1

195-02534C

SUPPORT

desc: . SUPPORT

1шт.

1-2

K1000806A

COVER

desc: . COUVERCLE

1шт.

1-3

621-02891

COVER

desc: . COUVERCLE

1шт.

1-4

S3050843

BOLT;WING

desc: . BOULON A AILES

6шт.

1-5

S5010513

WASHER

desc: . RONDELLE

6шт.

2

195-03410H

SUPPORT

desc: SUPPORT

1шт.

3

195-03336C

SUPPORT

desc: SUPPORT

1шт.

4

195-03339C

SUPPORT

desc: SUPPORT

1шт.

6

195-03342B

SUPPORT

desc: SUPPORT

1шт.

7

195-03341C

SUPPORT

desc: SUPPORT

1шт.

8

195-03434B

SUPPORT

desc: SUPPORT

1шт.

9

621-03655A

COVER;BAFFLE

desc: COUVERCLE

1шт.

18

DS0025015

BOLT;SET

desc: BOULON A 6 PANS

26шт.

19

K1006544

COVER;BAFFLE(R.H)

desc: COUVERCLE

1шт.

20

K1006559

COVER;BAFFLE(L.H)

desc: COUVERCLE

1шт.

21

621-01572

PLATE;STOPPER

desc: TAQUET D'ARRET

4шт.

22

DS0025022

BOLT;SET

desc: BOULON A 6 PANS

4шт.
