Запчасти Doosan Daewoo OIL PAN ENGINE PARTS

1

65.05801-5244

PAN;OIL

desc: CARTER MOTEUR

1шт.

2

65.98125-5022A

JOINT;DRAIN

desc: JOINT

1шт.

3

06.56190-0732

SEAL;RING

desc: CONTACT DE NIVEAU D'HUILE

1шт.

4

65.05904-0035

GASKET;OIL PAN

desc: JOINT

1шт.

5

06.01923-3120

BOLT ASS'Y M8X45

desc: BOULON A 6 PANS

22шт.

6

65.05806-5118

TUBE;OIL LEVEL GAUGE

desc: TUBE

1шт.

7

65.05805-5233B

OIL LEVEL GAUGE

desc: INDICATEUR DE NIVEAU D'HUILE

1шт.

8

65.05701-6113A

OIL PIPE ASS'Y

SERIAL: 061120

1шт.

8

65.05701-6121

OIL PIPE ASS'Y

SERIAL: 061121

1шт.

10

65.05740-0041

BRACKET;OIL SUCT.PIPE

desc: . SUPPORT

1шт.

11

65.97401-0137

CLIP;PIPE

desc: . ATTACHE

1шт.

12

06.01283-7115

BOLT M8X25

desc: . BOULON A 6 PANS

1шт.

13

06.15010-2311

WASHER

desc: . RONDELLE

1шт.

14

65.90510-0012

NUT

desc: . ECROU DE BLOCAGE

1шт.

15

65.05901-0027

GASKET

SERIAL: 060719

1шт.

15

65.05901-0032

GASKET

SERIAL: 060720

1шт.

16

06.01913-3115

BOLT ASS'Y M8X25

desc: BOULON A 6 PANS

1шт.

17

06.01913-3119

BOLT ASS'Y M8X40

SERIAL: 060719

2шт.

17

06.01013-9115

BOLT ASS'Y M8X50

SERIAL: 061120

2шт.

17

06.01913-3119

BOLT ASS'Y M8X50

SERIAL: 061121

2шт.
