Запчасти Doosan Daewoo CYLINDER HEAD ENGINE PARTS

-

K1022389

CYLINDER HEAD

SC: D

-2шт.

1

K1022390

CYLINDER HEAD ASSY

desc: CULLASSE

1шт.

1A

K1019240

VALVE;INTAKE

desc: . VALVE DE PRISE

4шт.

1B

K1019241

VALVE;EXHAUST

desc: . SOUPAPE D'ECHAPPEMENT

4шт.

1C

K1019242

PIN;ROLL

desc: . GOUPILLE

2шт.

1D

K1019243

SEAL;VALVE STEM

desc: . JOINT

8шт.

1E

K1019244

SPRING;VALVE

desc: . JOINT TORIQUE

8шт.

1F

K1019245

RETAINER;VALVE SPRING

desc: . ARRETOIR

8шт.

1G

K1019246

COLLET;VALVE

desc: . BAGUE

16шт.

1i

K1022391

HEAD;CYLINDER

SC: D

1шт.

1iA

K1019147

PLUG;PIPE

desc: .. PRISE

4шт.

1iB

K1019248

PLUG;EXPANSION

desc: .. PRISE

4шт.

1iC

K1019249

GUIDE;VALVE STEM

desc: .. GUIDE

4шт.

1iD

K1019250

GUIDE;VALVE STEM

desc: .. GUIDE

4шт.

1iE

K1019251

SEAT;ENGINE INTAKE VALVE

desc: .. SIEGE DE VALVE

4шт.

1iF

K1019252

SEAT;ENGINE EXHAUST VALVE

desc: .. SIEGE DE VALVE

4шт.

1iG

K1019253

PLUG;EXPANSION

desc: .. PRISE

2шт.

1iH

K1019149

PLUG;PIPE

desc: .. PRISE

5шт.

1iJ

K1019255

PLUG;DRIVE

desc: .. PRISE

4шт.

1iK

K1022378

CHAMBER;INJECTION

SC: D

4шт.

2

K1019256

GASKET;CYLINDER HEAD

desc: JOINT DE CULASSE

1шт.

3

K1019257

SCREW

desc: VIS

14шт.

4

K1019258

SCREW

desc: VIS

4шт.

5

K1019259

CAP;VALVE

desc: CAPUCHON

8шт.
