Запчасти Case TF300 (9-66) - DIGGING CHAIN GUARD, USED ON MODELS WITHOUT CRUMBER (09) - CHASSIS/ATTACHMENTS

1

H672301

GUARD ASSY.

GUARD - digging chain, trencher, used on models with 40 and 45 inch boom, includes decals, replaces H429118, if used

1шт.

1

H672300

SAFETY BELT

GUARD - digging chain, trencher, used on models with 54 and 66 inch boom, includes decals, replaces H429100, if used

1шт.

2

H607986

ARM

HANDLE - grab

1шт.

3

H54312

BOLT

U-BOLT - grab handle

2шт.

4

493-41078

LOCK WASHER,Ext Tooth, 3/4"

WASHER - external tooth lock, 3/4 inch

4шт.

5

230-4218

LOCK NUT,1/2"-13, GA

NUT - hex, self-locking, 1/2 inch NC

4шт.

6

413-1244

BOLT,Hex, 3/4" - 10 x 2-3/4", Gr 5

- hex, 3/4 NC x 2-3/4 inch

2шт.

7

493-41078

LOCK WASHER,Ext Tooth, 3/4"

WASHER - external tooth lock, 3/4 inch

4шт.
