Запчасти Case MAXI-SNEAKER (06-009A) - GROUND DRIVE MOTOR, 239920A2 (06) - POWER TRAIN

239920A2

HYDRAULIC MOTOR

ASSEMBLY trencher drive, Includes: Ref. 1 - 30

1шт.

1

251668A1

HOUSING

motor

1шт.

2

N13994

SPACER

PIN roll, special, housing to rear cover

2шт.

3

86625138

PLUG,7/18" - 14

Includes Ref. 3A

3шт.

3a

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.

4

251667A1

SHAFT

motor

1шт.

5

A29183

BALL BEARING,34.99mm ID x 71.99mm OD x 16.94mm W

ball

1шт.

6

100-11137

SNAP RING,#137, Ext

2шт.

8

N14103

SEAL

lip, shaft

1шт.

9

241589A1

SEALING WASHER,38.1mm ID x 71.75mm OD x 2.16mm Thk

seal support

1шт.

10

103-21281

SNAP RING,66.92mm ID x 2.36mm W, Int

2шт.

11

100700A1

PLATE

thrust

1шт.

100706A1

CYLINDER BLOCK

ASSEMBLY, Includes: Ref. 12 - 21

1шт.

12

NSS

NOT SOLD SEPARAT

PISTON cylinder block

9шт.

13

NSS

NOT SOLD SEPARAT

RETAINER piston

1шт.

14

NSS

NOT SOLD SEPARAT

GUIDE retainer

1шт.

15

NSS

NOT SOLD SEPARAT

PIN retaining, Serial Range: guide-shaft

3шт.

16

NSS

NOT SOLD SEPARAT

RING retaining

1шт.

17

NSS

NOT SOLD SEPARAT

BLOCK cylinder

1шт.

18

NSS

NOT SOLD SEPARAT

SEAT spring, block end

1шт.

19

NSS

NOT SOLD SEPARAT

SPRING cylinder block

1шт.

20

NSS

NOT SOLD SEPARAT

SEAT spring, cover end

1шт.

21

NSS

NOT SOLD SEPARAT

RING retaining

1шт.

22

100702A1

LARGE PLATE

PLATE, LARGE valve

1шт.

23

38-11210

LOCK PIN,3/16" x 5/8", Slotted

1шт.

24

100701A1

GASKET

cover

1шт.

25

F62094

NEEDLE BEARING

needle, shaft

1шт.

26

253471A1

PLUG

COVER end, with ports

1шт.

27

100703A1

PLATE, SPACER

PLATE,SPACER BRACKET lifting

1шт.

28

826-10080

BOLT,Hex, M10 x 1.5 x 80mm, Cl 10.9

hex, 10 - 1.5 x 80 mm, class 10.9

4шт.

29

218-5158

PLUG,Hex Hd, 1 1/16"-12 ORB

Not shown, Includes: Ref. 30

2шт.

30

237-6012

O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro

Not shown

1шт.
